| Channel |
2CH |
| Highlights |
Built-in 4G LTE, Sony STARVIS image sensors |
| Product Dimensions |
Front: Black / Width 137.6 mm x Height 43 mm / 159 g
Rear: Black / Width 67.4 mm x Height 25 mm / 25 g |
| Rear Camera Connection |
Coaxial cable |
| Memory Support |
microSD card up to 256GB |
| Recording Modes |
Normal recording, Event recording (when impact is detected in normal and parking mode), Manual recording and Parking recording (when motion is detected).
* When using Hardwiring Power Cable, ACC+ will trigger parking mode. When using other methods, G-sensor will trigger parking mode. |
| Parking Mode |
YES (with accessory) |
| Parking Mode Event Voice Notifications |
YES |
| Imaging Sensor |
Front: Sony STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel)
Rear: Sony STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel) |
| Viewing Angle |
Front: Diagonal 139°, Horizontal 116°, Vertical 61°
Rear: Diagonal 139°, Horizontal 116°, Vertical 61° |
| Resolution Frame Rate |
Front: Full HD (1920×1080) @ 60 fps
Rear: Full HD (1920×1080) @ 30 fps
* Frame rate may vary during Wi-Fi streaming. |
| Video Codec |
H.264 (AVC) |
| Image Quality and Bitrate Front/Rear |
Highest (Extreme): 25+10 Mbps
Highest: 12+10 Mbps
High: 10+8 Mbps
Normal: 8+6 Mbps |
| Format Free |
YES (Adaptive) |
| Event File Overwrite Protection |
YES (up to 50) |
| SD Card Failure Alert |
YES |
| Scheduled Reboot |
YES |
| Video File Extension |
MP4 |
| Wi-Fi |
Built-in (802.11n (2.4~2.4835 GHz)) |
| Cloud Compatible |
YES |
| GPS |
Built-in (Dual Band: GPS, GLONASS) |
| Microphone |
Built-in |
| Speaker |
Built-in |
| Impact Sensor |
3-Axis Acceleration Sensor |
| LED Indicators |
Front: Recording LED, GPS LED, B/W/L (Bluetooth/Wi-Fi/LTE) LED, Front Security LED
Rear: Rear Security LED |
| Operation Temperature |
-20 °C - 70 °C (-4 °F - 158 °F) |
| Storage Temperature |
-20 °C - 70 °C (-4 °F - 158 °F) |
| High Temp Cut Off |
Approx. 80 °C (176 °F) |
| Input Power |
DC 12V-24V (3 pole DC Plug (Ø3.5d x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC) |
| Power Consumption Hour |
Normal Mode (GPS On/Cloud On) : Avg. 470mA/12V
Normal Mode (GPS On/Cloud Off) : Avg. 410mA/12V
Parking Mode (GPS Off/Cloud On) : Avg. 370mA/12V
Parking Mode (GPS Off/Cloud Off) : Avg. 310mA/12V
* Actual power consumption may vary depending on use conditions and environment.
* Model DR770X-2CH LTE should be used only in circuits that satisfy Limited Power Source.
(Maximum power consumption is to be less than 100 VA or 8 A). |
| Certifications |
Front: FCC, ISED, CE, UKCA, RCM, Telec, RoHS, WEEE, KC
Rear: FCC, ISED, CE, UCKA, RCM, RoHS, WEEE, KC |
| Software |
BlackVue Viewer
* Windows 7 or higher, Mac Sierra OS X (10.12) or higher
BlackVue Web Viewer
* Chrome 71 or higher, Safari 13.0 or higher |
| Others |
Built-in 4G LTE module compatible with Nano-SIM.
Frequency Bands: B2, B4, B12 |
