Allen & Heath XB-14 2 Radio Broadcast Mixer
this item may be nonreturnable
Related Products
Features
- 4 x Mic/Line Channels
- 4 x Dual-Source Stereo Channels
- 2 x Telco Channels
- USB Sound Card for Mac & Windows
- Audition Bus, Aux Bus, Mix B
Description
The XB-14² by Allen & Heath is a broadcast mixer designed for self-operated broadcast applications in small radio and internet studios, as well as larger facilities with multiple rooms. It comes in a compact package and is packed with radio-friendly options usually found on large-format broadcast consoles.
This Mixer allows for an efficient and flexible workflow with features such as telephone-communication (Telco) channels, fader-start sensing, automatic muting of speaker outputs, stereo channel-start/cue outputs for CD deck-transport control, separate headphone mixes for guests, an audition bus, and more.
Separate monitor mixes can be created enabling the operator to cheque levels and cues without interfering with the listening sources of the presenter or guests. Using remote-interface connectors, mono channels can be remotely muted from studio-located mute or cough switches (available separately). In addition, the Talk to Guest switch allows for the operator to communicate off-air with guests, presenters, and telephone callers.
The audio circuitry of the XB-14² features four mic/line channels equipped with high-gain DuoPre preamps and 3-band EQs to help cut sibilance & mic popping, and 2-band EQs on stereo channels for use with music. The full-duplex USB sound card offers playback and record to & from a computer as well as voice over IP (VoIP), and is compliant with Mac & Windows core audio drivers.
Features
Flexible Routing Options
- Four mic/line mono channels
- Four dual-source stereo channels and a total of up to seven stereo sources
- Aux bus for external processing, effects, recording or auditioning
- Mix B for recording an independent mix to the main programme mix, or creating a clean feed source from selected channels
- Audition bus for auditioning or recording telephone conversations
- 27 logic I/O for remote control
- 15 configuration switches
- Output matrix with three headphone outs allows separate mixes for engineer/producer and two guests
- Talk button for off-air conversation with guests
DuoPre Preamps
The four mono channels feature DuoPre technology which employs a two-stage design to control the input gain structure of the channel. The first stage provides 69 dB of gain for the signal at the XLR input. The second stage is activated by plugging the signal into the TRS line-input jack. This gain-staging eliminates the need for pad circuit & pad switch, and ensures that the signal remains in the optimum region of its dynamic range for lower noise and distortion.
USB
The XB-14² is equipped with a stereo bi-directional sound card for playback, recording, or voice over IP (VoIP) to and from a computer. Its USB 1.1 audio codec is compliant with USB 2.0 ports and Windows & Mac core audio drivers.
Telco
Two Telco channels provide a selectable clean-feed output (L/R PGM, Aux or audition bus), variable high-pass and low-pass filters which are useful when a caller is connected via a low-quality telephone line, and a talk button that allows for communication with a telephone caller without the presenter's voice going to the programme mix.
Remote Control
The mono mic/line channels feature fader-start sensing to control external devices or to automatically mute speaker outputs to prevent feedback. The stereo channels are equipped with start & cue logic outputs used for CD deck transport control. Mic/line input channels can be remotely muted using an external "cough" switch (available separately).
Robust Construction
The XB-14² features individual vertically-mounted channel circuit boards with rotary controls fixed to the front panel using metal nuts. This robust construction allows for removing channels from the mixer one at a time and for easily changing faders, making servicing minimally disruptive.
Additional Features
- HPF and 3-band, swept-mid AEQ on mono channels
- 2-band AEQ on stereo channels
- Smooth-ride 100mm faders
- Auto-mute on control-room outputs
- XLR main outputs with inserts
- External-metre socket
- Input-signal and peak metering
Specifications
| Inputs | Mono Channel Mic Input (XLR): +6 to -63 dBu nominal / +17 dBu max Mono Channel Line Input (TRS Jack Socket): +10 to -26 dBu / +30 dBu max Insert Point (TRS Jack Socket): 0 dBu nominal / +21 dBu max Stereo Input (TRS Jack Sockets): 0 dBu nominal (control = off to +10 dBu) Stereo Input (RCA Phono Sockets): 0 dBu nominal (control = off to +10 dBu) Telco Channel Input (XLR): +10 to -26 dBu / +30 dBu max |
| Outputs | PGM L/R Outpu(XLR): +4 dBu nominal / +25 dBu max PGM Mono Output (RCA Phono): 0 dBu nominal / +21 dBu max PGM L & R inserts (TRS Jack Sockets): -2 dBu nominal / +21dBu max Aux Output (Jack Socket): 0 dBu nominal / +21 dBu max Mix B Outputs (RCA Phono Sockets): 0 dBu nominal / +21 dBu max Audition Outputs (RCA Phono Sockets): 0 dBu nominal / +21 dBu max CRM Outputs (RCA Phono Sockets): 0 dBu nominal / +21 dBu max Telco Output (XLR): 0 dBu nominal / +21 dBu max |
| THD + N | Mic In to PGM L/R Out: < 0.01% (0 dB Gain, 1 kHz, +10 dBu out) Mic In to PGM Out: < 0.01% (30 dB gain, 1 kHz, +10 dBu out) Line In to PGM L/R Out: < 0.01% (0 dB gain, 1 kHz, 0 dBu out) Stereo In to PGM Out: < 0.01% (0 dB gain, 1 kHz, +10 dBu out) |
| USB Audio Codec | USB Audio In/Out: USB 1.1 compliant / 16-bit Sample Rate: 32, 44.1, 48 kHz |
| Noise | Mic Pre EIN @ Maximum Gain: -124 dBu (150 R Input Z, 22 Hz to 22 kHz) PGM Out: < -100 dBu (PGM fader = 0, 22 Hz to 22 kHz) Audition Out: < -100 dBu (mix B out = 0, 22 Hz to 22 kHz) Aux Out: < -85 dBu (mono out = 0, 22 Hz to 22 kHz) |
| Headroom | Analogue Headroom from Nominal (O VU) Outputs: 21 dB Analogue Headroom from Nominal (O VU) Mix Point: 24 dB Headroom from Nominal (O VU): 14 dB |
| Crosstalk / Attenuation | Mono Fader Attenuation: -95 / -95 (dB relative to +10 dBu, 1 kHz to 10 kHz) Mono ON Switch Attenuation: -95 / -95 (dB relative to +10 dBu, 1 kHz to 10 kHz) TELCO Fader Attenuation: -95 / -95 (dB relative to +10 dBu, 1 kHz to 10 kHz) TELCO ON Switch Attenuation: -95 / -95 (dB relative to +10 dBu, 1 kHz to 10 kHz) Stereo Fader Attenuation: -95 / -90 (dB relative to +10 dBu, 1 kHz to 10 kHz) Stereo ON Switch Attenuation: -95 / -95 (dB relative to +10 dBu, 1 kHz to 10 kHz) PGM Fader Attenuation: -100 / -95 (dB relative to +10 dBu, 1 kHz to 10 kHz) TELCO Clean-Feed Isolation from I/P: -55 / -40 (dB relative to +10 dBu, 1 kHz to 10 kHz) Stereo Separation, L in to PGM R Out: -70 / -50 (dBr, 1 kHz to 10 kHz) |
| Frequency Response | Microphone In to PGM L/R Out: +0.5 / -1 dB, 10 Hz to 30 kHz (30 dB gain) Line In to PGM L/R Out: +0.5 / -1 dB, 10 Hz to 20 kHz (0 dB gain) Stereo In to PGM L/R Out: +0.5 / -1 dB, 10 Hz to 30 kHz |
| Power Supply | 100 - 240 V / 47 - 63 Hz |
| Power Consumption | 30 W |
| Fuse Rating | T 10 A / 250 V / 20 mm |
| Dimensions (W x H x D) | 385 x 103 x 465 mm |
| Weight | 7.5 kg |
In The Box
- Allen & Heath XB-14 2 Radio Broadcast Mixer
- AC Power Cord
- Type A-B USB Cable
