Audac IMP40 Sourcecon Internet Audio Player Module

Product #76963 | SKU IMP40 | Audac
In Stock with Supplier Usually ships in 2 - 3 working days what does this mean?
In Stock with Supplier Usually ships in 2 - 3 working days what does this mean?

Features

  • Professional internet radio player
  • Plug & play
  • No sudden channel hopping
  • Synchronizes with the vTuner database

Related Products

Audac DMP40 Sourcecon Dab/Dab+ & FM Tuner Module Audac DMP40 Sourcecon Dab/Dab+ & FM Tuner Module
Audac BMP40 Sourcecon Professional Bluetooth Module Audac BMP40 Sourcecon Professional Bluetooth Module

Description

The Audac IMP40 Sourcecon Internet Audio Player Module is a professional internet radio player featuring SourceCon™ modular technology. This unique technology guarantees true plug & play implementation to any compatible device. When inserted to a supporting slot, the module is instantly installed, discovered and ready for operation without requiring any additional internal wiring or complex configuration.

The IMP40 features the unique Linum™ technology which eliminates any unwanted behaviour such as sudden channel hopping or music stops. When the connection is interrupted, automatic switching to inserted media carriers (USB drives) avoids unpleasant silences in background music applications. The audio stream will be automatically and seamlessly restored afterwards. It synchronizes with the vTuner database which contains over 30.000 channels, allowing selection on different criteria such as genre, location, language, ... while custom streams can also be added to a preference list up to 100 entries.

The input connection is implemented by an RJ45 type connector with indicator LED’s on its panel, allowing connection to any ethernet network. The balanced stereo line output is connected through two 3-pin terminal block connections.

Specifications

SYSTEM SPECIFICATIONS
Connection SourceCon™ interface card slot
Inputs RJ45 (Ethernet)
Crosstalk (@ 1 kHz) 80 dB
THD+N (@ 1 kHz) < 0.07%
Supported filetypes Streaming MP3
WMA
AAC
Playback MP3
Compatible media Playback USB memory
USB HDD
Compatible filesystems Playback FAT16
FAT32
Outputs Type Balanced stereo line outputs
Level +8 dB ~ -92 dB
Frequency Response (± 3 dB) 20 Hz - 20 kHz
Power Consumption 1.5 W
PRODUCT FEATURES
Dimensions 87 x 34.5 x 114 mm (W x H x D)
Weight 0.070 kg
Mounting SourceCon™ interface card slot

In The Box

  • Audac IMP40 Sourcecon Internet Audio Player Module
