| Form Factor |
Desktop |
| Display |
1 x Multi-Segment LED Metre |
| Channels of I/O |
Analogue:
2 Inputs / 2 Outputs at 96 kHz |
| Maximum Sampling Rate |
96 kHz / 24-Bit |
| Number of Microphone Preamps |
2 Preamps |
| Input Level Adjustment |
2 x Automatic
1 x Knob |
| Expansion Slots |
None |
| Signal Processing |
|
| Pad |
None |
| Gain/Trim Range |
Mic/Line/Hi-Z Inputs:
58 dB |
| High-Pass Filter |
None |
| Solo/Mute |
Mute per Input Channel, Master |
| Connectivity |
|
| Analogue Audio I/O |
2 x Combo XLR-1/4" TRS Balanced Mic/Line Input
1 x 1/4" TS Unbalanced Hi-Z Input
2 x 1/4" TRS Balanced Monitor Output
1 x 1/4" TRS Unbalanced Headphone Output |
| Phantom Power |
48 V ± 4 V, Selectable On/Off (Selectable on Individual Inputs) |
| Phantom Power Current |
10 mA per Channel |
| Digital Audio I/O |
None |
| Host Connection / USB |
1 x USB Type-C |
| Host Connection Protocol |
USB 2.0 |
| USB (Non-Host) |
None |
| Sync I/O |
None |
| Network I/O |
None |
| MIDI I/O |
None |
| Wireless Connectivity |
None |
| Performance |
|
| Frequency Response |
Mic Inputs:
10 Hz to 40 kHz ±0.5 dB
Line, Hi-Z Inputs:
10 Hz to 20 kHz ±0.5 dB
A/D Convertors:
10 Hz to fs/2 ±0.5 dB
D/A Convertors:
10 Hz to fs/2 ±0.5 dB
Headphone Outputs:
10 Hz to fs/2 ±0.5 dB |
| Maximum Input Level |
Mic Inputs:
+16 dBu
Hi-Z Inputs:
+10 dBu |
| Maximum Output Level |
D/A Convertors:
+11 dBu |
| Headphone Output Power |
45 mW into 30 Ohms (Max)
52 mW into 60 Ohms (Max)
20 mW into 600 Ohms (Max) |
| Impedance |
Mic Inputs:
> 3 Kilohms (Balanced)
Line Inputs:
> 10 Kilohms (Balanced)
Hi-Z Inputs:
1 Megohm (Unbalanced) |
| Dynamic Range |
AD/DA Convertors:
113 dBA |
| SNR |
Mic/Line/Hi-Z Inputs:
100 dB |
| THD+N |
A/D Convertors:
< 0.001% (1 kHz, at -1 dBFS)
D/A Convertors:
< 0.0015% (1 kHz, at -1 dBFS)
Headphone Outputs:
< 0.0015% (1 kHz, at -1 dBFS)
Hi-Z Inputs:
< 0.3% (1 kHz)
Mic/Line Inputs:
< 0.0015% (1 kHz) |
| Crosstalk |
Mic/Line Inputs:
< -105 dBu
Monitor Outputs:
< 110 dBu
Headphone Outputs:
< -110 dBu
Inputs:
-105 dBu |
| EIN |
Mic/Line Inputs:
< -128 dB |
| CMRR |
Mic/Line Inputs:
> 85 dB |
| Digital Audio |
|
| dBFS Reference Level |
Inputs:
+8 dBu = 0 dBFS
Outputs:
+11 dBu = 0 dBFS |
| Sample Rates |
Up to 96 kHz |
| Sample Rate Conversion |
None |
| Bit Depths |
Up to 24-Bit |
| Latency |
5 ms at 44.1 kHz (Dependant on Buffer Size, Input to Output)
4.1 ms at 96 kHz (Dependant on Buffer Size, Input to Output) |
| Sync Sources |
Internal |
| Audio Storage & Playback |
|
| Memory Card Slot |
None |
| Compatibility |
|
| OS Compatibility |
macOS 10.7.5 or Later
Windows 7 or Later (32/64-Bit)
iOS 6 or Later
*As of November, 2021: Cheque with manufacturer for the most up-to-date compatibility |
| Included Software |
Cubase LE |
| Compatible Software (Not Included) |
Any Core Audio (Mac) Compliant Software |
| Supported Drivers/API & Plug-Ins |
Core Audio (Mac)
ASIO |
| Processor Requirement |
Mac:
Intel
PC:
1.6 GHz Intel Core 2
AMD |
| RAM Requirements |
1 GB |
| Required Hardware |
Available USB 2.0 Port
USB Cable (Included) |
| Internet Connection |
Required for Registration, Software/Driver Download |
| Power |
|
| Power Requirements |
USB Bus Power |
| Physical |
|
| Dimensions |
14 x 6.71 x 6.71 cm |
| Weight |
360.0 g |
