| Support Type |
Baseplate |
| Grip Type |
No |
| Mounting |
|
| Rod Standard |
15 mm LWS / 60 mm Spacing |
| Battery Plate Type |
No |
| Accessory Mounting |
Multiple 1/4"-20 Female Thread |
| Camera Mounting |
Quick Release Plate |
| Tripod Mounting |
ARRI Dovetail |
| Rod Ports |
2x 15 mm Rod Port |
| Shoe Mounting |
No |
| Rosettes |
No |
| Cable Clamp |
No |
| General |
|
| Dimensions |
4.9 x 4.4 x 1.3" / 12.5 x 11.1 x 3.3 cm |
| Weight |
11.2 oz / 317 g |
| Mount Type |
Multiple:
1/4"-20
3/8"-16:
ARRI accessory mounts |
| Dimensions |
3.9 x 2.6 x 0.3" / 10 x 6.7 x 0.8 cm |
| Weight |
2.6 oz / 75 g |
| Material of Construction |
Aluminium |
| Mounting |
6 x Captive Screws
Quick Release Dovetail Mechanism |
| Dimensions |
4.5 x 3.8 x 0.8" / 11.5 x 9.6 x 2.1 cm |
| Weight |
2.1 oz / 60 g |
| Material of Construction |
Hard-Anodised Aluminium, Rubber |
| Accessory Mounting Threads |
3 x M4 |
| Length |
4.5" / 115 mm |
| Weight |
1.7 oz / 50 g |
| Material of Construction |
Aluminium, Stainless Steel |
| Mounting |
Multiple 1/4"-20 Threads
Multiple 3/8"-16 ARRI-Style Accessory Mounts
1 x Integrated NATO Rail with Spring-Loaded Safety Stops
2 x Strap Holes |
| Dimensions |
4.7 x 2.9 x 0.6" / 12 x 7.4 x 1.6 cm |
| Weight |
3.5 oz / 100 g |
| Material of Construction |
Aluminium, Stainless Steel |
| Mounting Orientation |
Left Side, Requires Top Plate or Riser |
| Accessory Mounting Threads |
2 x 3/8"-16
2 x 1/4"-20 |
| Mounting Options |
1 x Integrated NATO Rail
1 x Shoe Mount |
| Dimensions |
5.4 x 2.3 x 0.5" / 13.6 x 5.9 x 1.3 cm |
| Weight |
1.9 oz / 55 g |
| Material of Construction |
Aluminium |
| Mounting Screw |
1 x Captive Screw |
| Cable Support |
2 x Captive Screw |
| Cable Compatibility |
HDMI
Width up to 0.4" / 10 mm |
| Force |
Pull Force up to 66 lb / 30 kg |
| Dimensions |
2.2 x 1.2 x 0.4" / 5.6 x 3 x 0.9 cm |
| Weight |
5.6 oz / 160 g |
| Key Specs |
|
| Item Type |
Topside Handle |
| Attachment Method |
Attaches via 1x Built-In Rail Clamp |
| Compatibility |
Attaches :
|
| Accessory Mounting |
Multiplex Anti-Twist 1/4"-20 Thread
Multiplex Anti-Twist 3/8"-16 Thread |
| Shoe Mounting |
1x Built-In Cold Shoe Slot |
| Rosettes |
No |
| Rail Mounting |
No |
| Rotation |
No |
| Built-In Controls |
No |
| Mounting |
|
| Attachment Method |
Attaches via 1x Built-In Rail Clamp |
| Compatibility |
Attaches :
|
| Accessory Mounting |
Multiplex Anti-Twist 1/4"-20 Thread
Multiplex Anti-Twist 3/8"-16 Thread |
| Shoe Mounting |
1x Built-In Cold Shoe Slot |
| Rosettes |
No |
| Rail Mounting |
No |
| General |
|
| Materials |
Aluminium |
| Dimensions |
5.9 x 2.6 x 1.3" / 15 x 6.7 x 3.4 cm |
| Weight |
8.1 oz / 231 g |
