Building upon the success of its predecessor, the Korg wavestate module Digital Wave Sequencing Synthesizer takes performance to new heights. This advanced instrument draws inspiration from the original Wavestation and utilizes the power of the OASYS and KRONOS keyboards. With its ability to create dynamic and evolving pads as well as captivating rhythms, the wavestate module is a versatile tool for musicians, producers, composers, and sound designers alike. Its compact 4 RU rackmount/desktop design ensures seamless integration into any stage, studio, or desktop setup, allowing for easy accessibility and convenience.
Korg wavestate module Digital Wave Sequencing Synthesizer
Contact us for an ETA
Our Price
$1,199
Contact us for an ETA
Email me when stock arrives
Features
- 4 RU Desktop / Rackmount Synthesiser
- Four Layers with Vector Control
- Wave Sequencing 2.0 Sound Engine
- 120 Stereo Voices + 4GB of Sample Storage
- 246 Performances and 756 Programmes
- 1042 Wave Sequences and User Storage
Description
Specifications
| Key Specs | |
| Sound Generation | Digital / Sample-Based |
| Number of Sounds, Kits, or Samples | 261x Factory Sound Preset 799x Factory Sound Preset 1024x Factory Sample |
| Maximum Polyphony | 96 Voice (Stereo) |
| Audio I/O | 2x 1/4" TRS Balanced Stereo Line Output 1x 1/4" TRS Unbalanced Stereo Headphone Output |
| MIDI I/O | 1x DIN 5-Pin Input 1x DIN 5-Pin Output |
| CV/Gate I/O | No |
| Patch Points | No |
| Horizontal Pitch | Not Specified by Manufacturer |
| General | |
| Item Type | Desktop Synth Module |
| Sound Generation | Digital / Sample-Based |
| Keyboard | No |
| Touch Sensitivity | Yes |
| Aftertouch | Channel/Mono or Polyphonic Aftertouch |
| Expression Controls | 1x Joystick 8x Knob |
| Number of Pads | No |
| Display | Monochrome LCD |
| Sounds | |
| Number of Sounds, Kits, or Samples | 261x Factory Sound Preset 799x Factory Sound Preset 1024x Factory Sample |
| Number of Song Presets | No |
| Maximum Polyphony | 96 Voice (Stereo) |
| Multitimbrality | Sample Library: 4-Part |
| Internal Memory | RAM: 4 GB |
| Built-In Effects | Yes |
| Performance Functions | Arpeggiator, Layer, Octave Shift, Sampler, Sequencer, Split/Layer, Transpose |
| Built-In Speaker | No |
| Synthesis | |
| Oscillators | 4x Variable (Wavetable) |
| Envelopes | 3x Assignable Envelope Generator |
| Filters | Characteristic: MS20-Style/Polysix-Style Type: Low-Pass, Band-Pass, High-Pass Slope: 2-Pole/12 dB (HPF/LPF/BPF) / 4-Pole/24 dB (HPF/LPF/BPF) |
| LFOs | Number of LFOs: 3x Global |
| Sequencing & Recording | |
| Sequencer | Number of Steps: 16 Input/Record Modes: Real-Time Record, Step Record |
| Motion Sequencing | Yes |
| Arpeggiator | Number of Arpeggio Patterns: 7 Modes: Up, Down, Random, Manual |
| Connectivity | |
| Audio I/O | 2x 1/4" TRS Balanced Stereo Line Output 1x 1/4" TRS Unbalanced Stereo Headphone Output |
| Pedal Support | 1x 1/4" Sustain |
| MIDI I/O | 1x DIN 5-Pin Input 1x DIN 5-Pin Output |
| CV/Gate I/O | No |
| Patch Points | No |
| Sync I/O | No |
| Network I/O | No |
| USB I/O | 1x USB-B (USB 2.0, Host Connection, MIDI) |
| Media/Memory Card Slot | No |
| Bluetooth | No |
| Compatibility | |
| OS Compatibility | macOS 10.12 to 13 / Windows 7 or Later |
| OS Compatibility | macOS 10.12 to 13 Windows 7 (32-/64-Bit) Windows 8 to 11 |
| Included Software | No |
| Mobile App Compatible | No |
| Required Hardware | USB 2.0 Port |
| Power | |
| Power Requirements | AC/DC Power Adapter (Included) |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| AC/DC Power Adapter | 12 VDC at 2500 mA (Included) |
| Power Consumption | 5 W |
| Physical | |
| Colour | Black |
| Rackmount Size | 4 RU |
| Horizontal Pitch | Not Specified by Manufacturer |
| Included Accessories | Power Cord |
| Dimensions | 19 x 6.8 x 4.5" / 48.3 x 17.3 x 11.4 cm |
| Weight | 3.8 lb / 1.7 kg |
In The Box
- Korg wavestate module Digital Wave Sequencing Synthesiser
- Power Adapter
Reviews
(no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:Give it a quick rating:
Thanks for your rating!
Write a review
Details
- Product: Korg wavestate module Digital Wave Sequencing Synthesizer
- Manufacturer: Korg
- Model: KOR-WAVESTATE-M
- SKU: KOR-WAVESTATE-M
- RM Product #: 118207
