| Key Specs |
|
| Number of Analogue Input Channels |
8 (2 Mono / 2 Stereo) |
| Number of Mic Preamps |
2 |
| Analogue Output Channels |
1x Stereo Master Output
1x Stereo Control Room/Monitor Output
1x Mono Aux Send Output
1x Stereo Tape/Record Output
1x Stereo Headphone Output |
| Mix Routing |
Main Mix per Mono Input Channel, Stereo Input Channel
Stereo Aux Bus/Subgroup per Stereo Input Channel |
| AEQ |
3-Band AEQ |
| Built-In Effects |
No |
| Wireless |
No |
| Rack Mountable |
No |
| Mixer |
|
| Number of Analogue Input Channels |
8 (2 Mono / 2 Stereo) |
| Number of Mic Preamps |
2 |
| Analogue Output Channels |
1x Stereo Master Output
1x Stereo Control Room/Monitor Output
1x Mono Aux Send Output
1x Stereo Tape/Record Output
1x Stereo Headphone Output |
| Mix Routing |
Main Mix per Mono Input Channel, Stereo Input Channel
Stereo Aux Bus/Subgroup per Stereo Input Channel |
| Faders & Level Adjustment |
4x Channel Knob
1x Bus/Subgroup Knob
1x Master Knob |
| Metres |
1x 4-Segment LED |
| Signal Processing |
|
| Gain/Trim Range |
Up to +10 dB |
| Sidechain Filters |
No |
| AEQ |
3-Band AEQ |
| AEQ Parameters |
High: ±15 dB at 12 kHz (Shelving)
Mid: ±15 dB at 2.5 kHz (Notch/Peak)
Low: ±15 dB at 80 Hz (Shelving) |
| Graphic AEQ |
No |
| Filters |
Low-Pass: 75 Hz, 18 dB/Octave |
| Solo/Mute |
No |
| Built-In Effects |
No |
| Performance |
|
| Frequency Response |
Mic Input to Output:
20 Hz to 30 kHz +0/-1 dB (Unity Gain) |
| Max Input Level |
XLR Mic Input:
+19 dBu
Aux Return:
+16 dBu
Line Input:
+21 dBu |
| I/O Impedance |
Mic Input:
3.8 Kilohms
Line Input:
≥ 10 Kilohms
Tape Output:
1 Kilohms
Headphone Output:
22 Ohms
Main Output:
120 Ohms (Unbalanced)
240 Ohms (Balanced) |
| Crosstalk |
Input to Output:
-85 dB at 1 kHz (20 Hz to 20 kHz)
Master Fader Off:
-75 dB at 1 kHz |
| CMRR |
> -70 dB at Max Gain (1 kHz, Mic In to Insert Send Out) |
| EIN |
-125 dBu at Max Gain |
| Noise Floor |
All Outputs:
-100 dBu (Master Level at -∞, Channel Levels at -∞)
-90 dBu (Master Level at Unity, Channel Levels at -∞)
-85 dBu (Master Level at Unity, One Channel Level at Unity) |
| THD+N |
Mic Input to Main Output:
< 0.25% (+4 dBu) |
| Connectivity |
|
| Analogue Inputs |
2x XLR 3-Pin Balanced/Unbalanced Mic Input
2x 1/4" TRS Balanced/Unbalanced Line Input
4x 1/4" TRS Balanced/Unbalanced Stereo Line Input (2 Stereo Pair)
2x 1/4" TRS Balanced/Unbalanced Aux Return
1x Stereo RCA Coaxial Unbalanced Tape Input (1 Stereo Pair) |
| Analogue Outputs |
2x 1/4" TRS Balanced/Unbalanced Stereo Main Output (1 Stereo Pair)
1x 1/4" TRS Mono Aux Send
1x 1/4" TRS Stereo Headphone Output
1x Stereo RCA Coaxial Unbalanced Stereo Tape Output (1 Stereo Pair)
1x Stereo RCA Coaxial Unbalanced Stereo Tape Output (1 Stereo Pair) |
| Phantom Power |
No |
| Digital I/O |
No |
| Wireless |
No |
| Power |
|
| AC Input Power |
120 VAC, 60 Hz
230 VAC, 50 / 60 Hz |
| Power Supply Output |
18 VAC at 1000 mA |
| Physical |
|
| Rack Mountable |
No |
| Dimensions |
2.1 x 7.8 x 9.6" / 53 x 198 x 244 mm |
| Weight |
2.5 lb / 1.1 kg |
