Key Specs |
|
Lens Mount |
Micro Four Thirds |
Sensor Resolution |
Actual: 26.52 Megapixel Effective: 25.21 Megapixel |
Image Sensor |
17.3 x 13 mm (Four Thirds) MOS |
Image Stabilisation |
Sensor-Shift, 5-Axis |
ISO Sensitivity |
Photo 100 to 25,600 (Extended: 50 to 25,600) Video 100 to 12,800 (Extended: 50 to 12,800) |
Continuous Shooting |
Mechanical Shutter Up to 14 fps at 25.2 MP for up to 170 Frames (Raw) / 200 Frames (JPEG) Electronic Shutter Up to 75 fps at 25.2 MP for up to 200 Frames (Raw) / 200 Frames (JPEG) |
Internal Recording Modes |
H.264 ALL-Intra/H.265 Long GOP 4:2:2/4:2:0 8/10-Bit 5760 x 4320 at 23.98/24.00/25/29.97 fps [200 Mb/s] 5728 x 3024 at 23.98/24.00/25/29.97/47.95/48.00/50/59.94 fps [200 to 300 Mb/s] 4352 x 3264 at 47.95/48.00/50/59.94 fps [300 Mb/s] 4096 x 2160 at 23.98/24.00/25/29.97/47.95/50/59.94/100/120 fps [150 to 600 Mb/s] 3840 x 2160 at 23.98/24.00/25/29.97/47.95/50/59.94/100/120 fps [72 to 600 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/47.95/50/59.94/100/120/200/240/300 fps [20 to 400 Mb/s] ProRes 422/ProRes 422 HQ 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps [121 to 454 Mb/s] |
External Recording Modes |
4:2:2 10-Bit via USB 5728 x 3024 at 23.98/24.00/25/29.97 fps 4096 x 2160 at 23.98/24.00/25/29.97/47.95/50/59.94 fps 3840 x 2160 at 23.98/24.00/25/29.97/47.95/50/59.94 fps 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/200/240 fps |
Media/Memory Card Slot |
Dual Slot: SD/SDHC/SDXC (UHS-II) |
Wireless |
2.4 / 5 GHz Wi-Fi 5 (802.11ac) Bluetooth 5.0 |
Mobile App Compatible |
Yes: Android & iOS App Name: LUMIX Sync Functionality: Access Stored Files, Adjust Settings, Firmware Update, Remote Control *As of September, 2023: Cheque with manufacturer for the most up-to-date compatibility |
Built-In Flash/Light |
No |
Battery Type |
1 x DMW-BLK22 Rechargeable Lithium-Ion, 7.2 VDC, 2200 mAh (Approx. 370 Shots) |
Imaging |
|
Lens Mount |
Micro Four Thirds |
Sensor Resolution |
Actual: 26.52 Megapixel Effective: 25.21 Megapixel |
Image Sensor |
17.3 x 13 mm (Four Thirds) MOS |
Crop Factor |
2x |
Image Stabilisation |
Sensor-Shift, 5-Axis |
Built-In ND Filter |
None |
Capture Type |
Stills & Video |
Exposure Control |
|
Shutter Type |
Electronic Shutter, Mechanical Focal Plane Shutter |
Shutter Speed |
Mechanical Shutter 1/8000 to 60 Seconds Up to 30 Minutes in Bulb Mode Electronic Shutter 1/32000 to 60 Seconds Up to 60 Seconds in Bulb Mode Electronic Front Curtain Shutter 1/2000 to 60 Seconds Up to 30 Minutes in Bulb Mode |
Bulb/Time Mode |
Bulb Mode |
ISO Sensitivity |
Photo 100 to 25,600 (Extended: 50 to 25,600) Video 100 to 12,800 (Extended: 50 to 12,800) |
Metering Method |
Centre-Weighted Average, Highlight Weighted, Multiple, Spot |
Exposure Modes |
Aperture Priority, Auto, Manual, Programme, Shutter Priority |
Exposure Compensation |
-5 to +5 EV (1/3 EV Steps) |
Metering Range |
0 to 18 EV |
White Balance |
2500 to 10,000K Presets: AWB, Cloudy, Colour Temperature, Daylight, Flash, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4 |
Continuous Shooting |
Mechanical Shutter Up to 14 fps at 25.2 MP for up to 170 Frames (Raw) / 200 Frames (JPEG) Electronic Shutter Up to 75 fps at 25.2 MP for up to 200 Frames (Raw) / 200 Frames (JPEG) |
Interval Recording |
Yes |
Self-Timer |
2/10-Second Delay |
Still Image Capture |
|
Image Sizes |
4:3 100 MP (11,552 x 8672) *Via In-Camera Pixel-Shift 100 MP (8192 x 6144) *Via In-Camera Pixel-Shift 25.2 MP (5776 x 4336) 25.2 MP (4096 x 3072) 25.2 MP (2944 x 2208) 3:2 100 MP (11,552 x 7696) *Via In-Camera Pixel-Shift 100 MP (8192 x 5464) *Via In-Camera Pixel-Shift 25.2 MP (5776 x 3848) 25.2 MP (4096 x 2728) 25.2 MP (2944 x 1960) 16:9 100 MP (11,552 x 6496) *Via In-Camera Pixel-Shift 100 MP (8192 x 4608) *Via In-Camera Pixel-Shift 25.2 MP (5776 x 3248) 25.2 MP (4096 x 2304) 25.2 MP (2944 x 1656) 1:1 100 MP (8672 x 8672) *Via In-Camera Pixel-Shift 100 MP (6144 x 6144) *Via In-Camera Pixel-Shift 25.2 MP (4336 x 4336) 25.2 MP (3072 x 3072) 25.2 MP (2208 x 2208) |
Aspect Ratio |
1:1, 3:2, 4:3, 16:9 |
Image File Format |
JPEG, Raw |
Video Capture |
|
Internal Recording Modes |
H.264 ALL-Intra/H.265 Long GOP 4:2:2/4:2:0 8/10-Bit 5760 x 4320 at 23.98/24.00/25/29.97 fps [200 Mb/s] 5728 x 3024 at 23.98/24.00/25/29.97/47.95/48.00/50/59.94 fps [200 to 300 Mb/s] 4352 x 3264 at 47.95/48.00/50/59.94 fps [300 Mb/s] 4096 x 2160 at 23.98/24.00/25/29.97/47.95/50/59.94/100/120 fps [150 to 600 Mb/s] 3840 x 2160 at 23.98/24.00/25/29.97/47.95/50/59.94/100/120 fps [72 to 600 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/47.95/50/59.94/100/120/200/240/300 fps [20 to 400 Mb/s] ProRes 422/ProRes 422 HQ 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps [121 to 454 Mb/s] |
External Recording Modes |
4:2:2 10-Bit via USB 5728 x 3024 at 23.98/24.00/25/29.97 fps 4096 x 2160 at 23.98/24.00/25/29.97/47.95/50/59.94 fps 3840 x 2160 at 23.98/24.00/25/29.97/47.95/50/59.94 fps 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/200/240 fps |
Fast-/Slow-Motion Support |
Yes |
Gamma Curve |
HDR-HLG, Panasonic V-Gamut, Panasonic V-Log |
Recording Limit |
None |
Broadcast Output |
NTSC/PAL |
IP Streaming |
None |
Built-In Microphone Type |
Stereo |
Audio Recording |
MOV: 2-Channel 24-Bit 48 kHz LPCM Audio MP4: 2-Channel 16-Bit 48 kHz AAC Audio |
Interface |
|
Media/Memory Card Slot |
Dual Slot: SD/SDHC/SDXC (UHS-II) |
Video I/O |
1 x HDMI (Unspecified Signal) Output |
Audio I/O |
1 x 1/8" / 3.5 mm TRS Stereo Headphone Output on Camera Body 1 x 1/8" / 3.5 mm TRS Stereo Microphone Input on Camera Body |
Power I/O |
1 x USB-C Input/Output |
Other I/O |
1 x USB-C (USB 3.2 / 3.1 Gen 2) Data/Video Input/Output (Shared with Power Input) |
Wireless |
2.4 / 5 GHz Wi-Fi 5 (802.11ac) Bluetooth 5.0 |
Mobile App Compatible |
Yes: Android & iOS App Name: LUMIX Sync Functionality: Access Stored Files, Adjust Settings, Firmware Update, Remote Control *As of September, 2023: Cheque with manufacturer for the most up-to-date compatibility |
Global Positioning (GPS, GLONASS, etc.) |
GPS *Via Connected Smartphone |
Monitor |
|
Display Size |
3" |
Resolution |
1,840,000 Dot |
Display Type |
Articulating Touchscreen LCD |
Viewfinder |
|
Type |
Built-In Electronic (OLED) |
Resolution |
3,680,000 Dot |
Eye Point |
21 mm |
Coverage |
100% |
Magnification |
Approx. 0.8x |
Dioptre Adjustment |
-4 to +2 |
Focus |
|
Focus Type |
Auto and Manual Focus |
Focus Mode |
Continuous-Servo AF, Manual Focus, Single-Servo AF |
Autofocus Points |
Phase Detection: 779 |
Autofocus Sensitivity |
-4 to +18 EV |
Flash |
|
Built-In Flash/Light |
No |
Maximum Sync Speed |
1/250 Second |
Flash Compensation |
-3 to +3 EV (1/3 EV Steps) |
Dedicated Flash System |
TTL |
External Flash Connection |
Shoe Mount, Wireless |
Environmental |
|
Operating Temperature |
14 to 104°F / -10 to 40°C |
Operating Humidity |
10 to 80% |
General |
|
Battery Type |
1 x DMW-BLK22 Rechargeable Lithium-Ion, 7.2 VDC, 2200 mAh (Approx. 370 Shots) |
Shoe Mount |
1 x Hot Shoe |
Tripod Mounting Thread |
1 x 1/4"-20 Female (Bottom) |
Material of Construction |
Magnesium Alloy |
Dimensions (W x H x D) |
5.3 x 4 x 3.5" / 134.3 x 102.3 x 90.1 mm (Without Protrusions) |
Weight |
1.4 lb / 658 g (With Battery, Recording Media) 1.3 lb / 575 g (Body Only) |
