| Imaging |
|
| Lens Mount |
Micro Four Thirds |
| Sensor Resolution |
Actual: 21.77 Megapixel
Effective: 20.3 Megapixel (8176 x 1920) |
| Image Sensor |
17.3 x 13 mm (Four Thirds) MOS |
| Sensor Crop (35mm Equivalent) |
Crop Factor: 2x
Additional Crop Occurs in Select Video Modes |
| Image Stabilisation |
Sensor-Shift, 5-Axis |
| Built-In ND Filter |
No |
| Capture Type |
Stills & Video |
| Exposure Control |
|
| Shutter Type |
Mechanical Focal Plane Shutter and Electronic Rolling Shutter |
| Shutter Speed |
Electronic Shutter
1/16000 to 1 Second
Electronic Front Curtain Shutter
1/2000 to 60 Seconds |
| Bulb/Time Mode |
Bulb Mode |
| ISO Sensitivity Range |
200 to 25,600 (Extended: 100 to 25,600)
Video
200 to 6400 in Auto Mode (Extended: 100 to 6400) |
| Metering Method |
Centre-Weighted Average, Multiple, Spot |
| Exposure Modes |
Aperture Priority, Auto, Manual, Programme, Shutter Priority |
| Exposure Compensation |
-5 to +5 EV (1/3 EV Steps) |
| Metering Range |
0 to 18 EV |
| White Balance |
Presets: Auto, Cloudy, Colour Temperature, Daylight, Flash, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4 |
| Continuous Shooting |
Up to 9 fps at Maximum Resolution for up to 30 Frames (Raw) / 600 Frames (JPEG) |
| Interval Recording |
Yes |
| Self-Timer |
10-Second Delay |
| Still Image Capture |
|
| Aspect Ratio |
1:1, 3:2, 4:3, 16:9 |
| Image File Format |
JPEG, Raw |
| Video Capture |
|
| Internal Recording Modes |
AVCHD
1920 x 1080p at 24.00/60.00 fps [24 to 28 Mb/s]
1920 x 1080i at 60.00 fps [17 to 29.98 Mb/s]
MP4
UHD 4K (3840 x 2160) at 24.00/30.00 fps [100 Mb/s]
1920 x 1080p at 30.00/60.00 fps [20 to 28 Mb/s]
1280 x 720 at 30.00 fps [10 Mb/s] |
| External Recording Modes |
HDMI
DCI 4K (4096 x 2160) |
| Fast-/Slow-Motion Support |
Slow-Motion Only |
| Recording Limit |
No |
| IP Streaming |
No |
| Built-In Microphone |
Stereo |
| Audio Recording |
AAC Audio |
| Interface |
|
| Media/Memory Card Slot |
Single Slot: SD/SDHC/SDXC (UHS-II) |
| Video I/O |
1x Micro-HDMI Output |
| Audio I/O |
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
1x 1/8" / 3.5 mm TRS Stereo Microphone Input |
| Power I/O |
1x USB-C Input |
| Other I/O |
1x 2.5 mm Sub-Mini Remote Input
1x USB-C Data Output (Shared with Power Input) |
| Wireless |
Wi-Fi 4 (802.11n), Bluetooth 5.0 |
| Mobile App Compatible |
Yes: Android & iOS
App Name: Panasonic Image App
Functionality: Access Stored Files, Remote Control, View Live Feed |
| Global Positioning (GPS, GLONASS, etc.) |
GPS
Via Connected Smartphone |
| Monitor |
|
| Display Size |
3.0" |
| Resolution |
1,840,000 Dot |
| Display Type |
Articulating Touchscreen OLED |
| Viewfinder |
|
| Type |
Electronic (OLED) |
| Resolution |
2,360,000 Dot |
| Eye Point |
20 mm |
| Coverage |
100% |
| Magnification |
Approx. 0.74x |
| Dioptre Adjustment |
-4 to +4 |
| Focus |
|
| Focus Type |
Auto and Manual Focus |
| Focus Mode |
Automatic, Continuous-Servo AF, Flexible, Manual Focus |
| Autofocus Points |
Contrast Detection: 49 |
| Flash |
|
| Built-In Flash/Light |
Yes, Flash Only |
| Flash Modes |
Auto, Auto/Red-Eye Reduction, Forced On, Forced On/Red-Eye Reduction, Off, Slow Sync, Slow Sync/Red-Eye Reduction |
| Guide Number |
9' / 2.7 m at ISO 200 |
| Maximum Sync Speed |
1/200 Second |
| Flash Compensation |
-3 to +3 EV (1/3 EV Steps) |
| Dedicated Flash System |
TTL |
| External Flash Connection |
Shoe Mount |
| General |
|
| Battery |
1x Rechargeable Lithium-Ion, 7.2 VDC, 1200 mAh (Included)
• Approx. 290 Shots |
| Shoe Mount |
1x Hot Shoe |
| Tripod Mounting Thread |
1x 1/4"-20 Female (Bottom) |
| Material of Construction |
Magnesium Alloy |
| Operating Conditions |
14 to 104°F / -10 to 40°C at 10 to 80% Humidity |
| Dimensions (W x H x D) |
5.1 x 3.7 x 3" / 130.4 x 93.5 x 77.4 mm |
| Weight |
1.1 lb / 478 g (Body Only)
1.2 lb / 530 g (With Battery, Recording Media) |
| Kit Lens |
|
| Focal Length |
12 to 60mm (35mm Equivalent: 24 to 120mm) |
| Maximum Aperture |
f/3.5 to 5.6 |
| Minimum Aperture |
f/22 |
| Angle of View |
84.05° to 20.44° |
| Maximum Magnification |
0.27x |
| Minimum Focus Distance |
7.87" / 20 cm |
| Optical Design |
11 Elements in 9 Groups |
| Diaphragm Blades |
7, Rounded |
| Focus Type |
Autofocus |
| Image Stabilisation |
Yes |
| Filter Size |
58 mm (Front) |
| Dimensions (ø x L) |
2.6 x 2.8" / 66 x 71 mm |
| Weight |
7.4 oz / 210 g |
