The Parallel Audio LIVE-HM Wireless Headset System has 100 factory preset user-selectable UHF frequencies. Advanced microprocessor control, excellent RF design with improved signal performance for interference free multi-channel operation. Patented IrDA technology for 2-way sync between transmitter and receiver. SCAN function automatically locates the next clean frequency. More than 10-12 non interfering channels can be operated simultaneously within a selected 25MHz bandwidth. Diversity design for high sensitivity, high selectivity, and high image/spurious rejections. LCD display on the receiver shows selected frequency. Antennas can be either rear or front mounted. Anti-interference Pilotone control and RF noise squelch circuitries. RF & AF LED indicators. Balanced (XLR) x 1 / unbalanced (O6.3mm) x 1 audio outputs. Half-rack metal chassis, mountable with optional mount kit(PA-WRK-1 for 1 unit, PA-WRK-2 for 2 units). Matching transmitters: HH6100, BP6100. Receiver provides power for Parallel Audio antenna systems to enhance reception range and signal stability.
Parallel Audio LIVE-HM Wireless Headset System
Usually ships in 1 - 2 weeks
Our Price
$809
Usually ships in 1 - 2 weeks
Email me when stock arrives
Shipping & Availability
Usually ships in 1 - 2 weeks.
Deliver to
Auckland
for $15
Change location
Click & Collect Availability
Wellington
Out of stock.
Pickup in
1 - 2 weeks
Click & Collect
Features
- 100 factory preset UHF frequencies
- Advanced microprocessor control
- Excellent RF design
- Patented IrDA technology
- SCAN function
- Diversity design
Description
Specifications
| Channel | Single |
| Chassis | EIA standard 19" 1/2U |
| Frequency range | UHF 520-675MHz (3 available bands) |
| Bandwidth | Up to 25MHz |
| Receiving mode | Diversity |
| Peak deviation | ñ40kHz |
| Channel sync | 2-way (receiver - transmitter) |
| Sensitivity | S/N > 80dBm at 10dB?¬V |
| S/N ratio | > 110dB (A) |
| T.H.D. | < 0.5% @ 1kHz |
| Frequency response | 50Hz - 18kHz |
| Receiving antenna | Rear Panel. Detachable. |
| Preset channels | 100 |
| Oscillation mode | PLL synthesised, frequency stability ??ñ 0.005% (-10 - +60C) |
| Squelch | Pilotone & Noise-cancelling dual-squelch circuit |
| Audio output adjustment | Gain control circuit for adjustment of output volume |
| Output connector | Balanced XLR and unbalanced 6.3?? |
| Power supply | 12V DC, 1.0A |
| Power consumption | 12W |
| Dimensions (mm) | 200 (W) x 44 (H) x 150 (D) |
| Weight (kg) | 0.63 |
In The Box
- Live-100 Wireless Receiver
- BP6100 Beltpack Transmitter
- HM-221-U/O Headworn Mic (Beige)
Reviews
(no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:Give it a quick rating:
Thanks for your rating!
Write a review
Details
- Product: Parallel Audio LIVE-HM Wireless Headset System
- Manufacturer: Parallel Audio
- Model: LIVE-HM
- SKU: LIVE-HM
- RM Product #: 116963
- System Type: Headset System
