| Imaging |
|
| Sensor Resolution |
Actual: 23.9 Megapixel
Effective: 22.3 Megapixel (5760 x 3840) |
| Image Sensor |
18.4 x 12.3 mm (1.4"-Type) CMOS |
| Image Stabilisation |
Optical in Integrated Lens
Digital (Video Only) |
| Lens |
|
| Focal Length |
8.2 to 25.6mm (35mm Equivalent: 16 to 50mm) |
| Optical Zoom |
3.1x |
| Maximum Aperture |
f/2.8 to 4.5 |
| Minimum Aperture |
f/11 |
| Focus Range |
2" to Infinity / 5 cm to Infinity (Wide)
5.9" to Infinity / 15 cm to Infinity (Telephoto) |
| Optical Design |
9 Elements in 8 Groups |
| Exposure Control |
|
| Shutter Speed |
Mechanical Shutter
1/2000 to 30 Seconds
Electronic Shutter
1/16000 to 30 Seconds |
| Bulb/Time Mode |
Bulb Mode |
| ISO Sensitivity Range |
100 to 32,000 (Extended: 100 to 51,200)
Video
100 to 12,800 (Extended: 100 to 25,600) |
| Metering Method |
Centre-Weighted Average, Evaluative, Partial |
| Exposure Modes |
Aperture Priority, Auto, Manual, Programme, Shutter Priority |
| Exposure Compensation |
-3 to +3 EV (1/3 EV Steps) |
| White Balance |
Presets: Auto, Cloudy, Colour Temperature, Flash, Fluorescent (White), Incandescent, Manual, Shade, Sunlight |
| Continuous Shooting |
Up to 30 fps at Maximum Resolution |
| Interval Recording |
Yes |
| Self-Timer |
2/10-Second Delay |
| Still Image Capture |
|
| Aspect Ratio |
3:2 |
| Image File Format |
HEIF, JPEG, Raw |
| Bit Depth |
14-Bit |
| Video Capture |
|
| Internal Recording Modes |
H.264/H.265
UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94 fps [60 to 340 Mb/s]
1920 x 1080 at 23.98/29.97/50/59.94/100/120 fps [12 to 180 Mb/s] |
| Recording Limit |
No |
| IP Streaming |
No |
| Built-In Microphone |
Stereo (Microphone Location: Top) |
| Interface |
|
| Media/Memory Card Slot |
Single Slot: SD/SDHC/SDXC (UHS-II) |
| Internal Memory |
No |
| Video I/O |
1x Micro-HDMI Output |
| Audio I/O |
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
1x 1/8" / 3.5 mm TRS Stereo Microphone Input |
| Power I/O |
1x USB-C Input |
| Other I/O |
1x USB-C (USB 2.0) Data Output (Shared with Power Input) |
| Wireless |
2.4 GHz Wi-Fi 4 (802.11n) Control |
| Mobile App Compatible |
Yes: Android & iOS
App Name: Canon Camera Connect
Functionality: Access Stored Files, Adjust Settings, Remote Control, View Live Feed |
| Global Positioning (GPS, GLONASS, etc.) |
No |
| Monitor |
|
| Display Size |
3" |
| Resolution |
1,040,000 Dot |
| Display Type |
Articulating Touchscreen LCD |
| Viewfinder |
|
| Type |
No Viewfinder Support |
| Flash |
|
| Built-In Flash/Light |
No |
| External Flash Connection |
Shoe Mount |
| General |
|
| Operating Conditions |
32 to 104°F / 0 to 40°C at 10 to 90% Humidity |
| Battery |
1x LP-E17 Rechargeable Lithium-Ion (Included) |
| Shoe Mount |
1x Intelligent Hot Shoe |
| Dimensions (W x H x D) |
4.7 x 2.7 x 2.1" / 118.3 x 68 x 52.5 mm |
| Weight |
13.4 oz / 379 g (Body Only) |
