Radial Engineering Catapult TX4L 4-Channel for Line-Level Signal Routing over Cat5/6 (Transmitter)

Product #119776 | SKU RA-CAT-TX4L | Radial
Usually ships in 2 - 3 weeks what does this mean?
Our Price $609
Usually ships in 2 - 3 weeks what does this mean?
- +

Email me when stock arrives

Shipping & Availability
Usually ships in 2 - 3 weeks. Deliver to Auckland for $8.90 Change location
Click & Collect Availability
Wellington Out of stock. Pickup in 2 - 3 weeks
Click & Collect

Features

  • For Routing Line-Level Audio via Cat5/6
  • For Use with Catapult RX4L
  • 4 x XLR Inputs
  • 4 x Line-Level Isolated Outputs
  • 1 x RJ45 Output, 1 x RJ45 Through-Output
  • For Live-Sound Applications

Description

The Radial Engineering Catapult TX4L 4-Channel for Line-Level Signal Routing over Cat5/6 is a versatile four-channel snake that utilizes shielded Cat5/Cat6 cable to route line-level signals across long distances with minimal signal degradation. Live sound technicians can benefit from using this snake in live-sound reinforcement applications to ensure quality audio connections around large stages and venues without breaking the bank. Additionally, system contractors can take advantage of pre-wired networks to distribute audio throughout various rooms thanks to the Catapult TX4L. Featuring four XLR input jacks, four XLR transformer-balanced through-outputs, and two RJ45-type etherCON connections, this tool offers flexibility and functionality for splitting and routing line-level signals across multiple locations. With a ground-lift switch to eliminate noise issues, a steel handle for easy transportation, and protective bumpers for the Ethernet jacks and switches, the Catapult TX4L is a reliable and durable solution for audio routing needs.

Specifications

Audio Circuit Type Passive line splitter, transformer based
I/O 4 x XLR inputs
4 x XLR through-outputs
1 x RJ45-type etherCON output
1 x RJ45-type etherCON through-output
Frequency Response 7 Hz to approximately 20 kHz
Total Harmonic Distortion 0.0007% at 1 kHz
Dynamic Range 140 dB
Maximum Input +35 dBu
Minimum Load Impedance 100 Ohms
Intermodulation Distortion 0.003%
Common Mode Rejection > 113 dB
Ground Lift Disconnects ground on RJ45 connector
Construction 14-gauge steel chassis and outer shell
Finish Durable powder coat
Dimensions 8.1 x 4.1 x 2.0" / 20.6 x 10.5 x 5.1 cm
Weight 2.6 lb / 1.2 kg

In The Box

  • Radial Engineering Catapult TX4L 4-Channel for Line-Level Signal Routing over Cat5/6 (Transmitter)

Reviews

0.0 (no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:
Write a review

Details

  • Product: Radial Engineering Catapult TX4L 4-Channel for Line-Level Signal Routing over Cat5/6 (Transmitter)
  • Manufacturer: Radial
  • Model: Catapult TX4L
  • SKU: RA-CAT-TX4L
  • RM Product #: 119776
  • Warranty: 5 year manufacturer warranty
