StarTech 2-Port Dual DisplayPort USB KVM Switch with Audio & USB 2.0 Hub

Product #78003 | SKU SV231DPDDUA | Startech
In stock Ships direct Monday
Our Price $939.00
In stock Ships direct Monday
- +

this item may be nonreturnable
Shipping & Availability
Ships Monday. Deliver to Auckland for $7.90 Change location
Click & Collect Availability
Wellington Out of stock. Pickup in 3 - 4 working days
Click & Collect

Features

  • Dual DisplayPort Connections
  • 2560 x 1600 @ 60 Hz Resolutions
  • 7.1 Channel HD Digital Audio
  • Integrated 2-Port USB 2.0 Hub
  • Plug-&-Play Support

Related Products

StarTech DisplayPort 1.2 Male-to-Male Cable with Latches (1.8m) StarTech DisplayPort 1.2 Male-to-Male Cable with Latches (1.8m)
StarTech DisplayPort 1.2 Male-to-Male Cable with Latches (3m) StarTech DisplayPort 1.2 Male-to-Male Cable with Latches (3m)
StarTech Mini DisplayPort Male to DisplayPort Male Adapter Cable (1.8m, Black) StarTech Mini DisplayPort Male to DisplayPort Male Adapter Cable (1.8m, Black)

Description

The StarTech 2-Port Dual DisplayPort USB KVM Switch with Audio & USB 2.0 Hub combines next generation digital display standards with seamless KVM control, allowing you to switch between 2 dual head or twin DisplayPort systems. It is also ideal for systems with a single DisplayPort output and a second video source such as DVI or HDMI using a low-cost accessory adapter.

Delivering multi-computer control for high-res multimedia applications, the dual view KVM supports resolutions of 2560 x 1600 (@ 60 Hz) with DisplayPort HD audio as well as 2-channel analogue stereo audio and microphone input. Suitable for high-quality static imaging, such as medical applications (MRI, X-ray and more), a maximum resolution of 3840 x 2400 is supported at lower refresh rates.

Key Features:

  • Native dual DisplayPort connections - no adapter required
  • Supports 2560 x 1600 @ 60 Hz resolutions; beyond 1080p
  • Maximum resolutions of 3840 x 2400 at lower refresh rates
  • 1 channel high definition digital audio supported via the DisplayPort interface
  • 14" (3.5mm) 2-channel stereo audio and microphone
  • Integrated 2-port USB 2.0 hub provides peripheral sharing to eliminate the expense of duplicate devices (printers, scanners and more)
  • No driver or software installation required
  • OS independent
  • Hotkey and push button switching
  • Full plug-and-play support with USB console interfaces
  • User-defined scan time intervals
  • USB 2.0 hub and audio can be switched independently
  • Supports hot-plug, un-plug and link status-failure detection
  • Supports DDC2B for monitor detection
  • Small form factor design with rear connection ports
  • Versatile KVM solution works well with Mini-DisplayPort, DisplayPort to DVI or HDMI adapters; perfect for Dual DisplayPort or DisplayPort + DVI or HDMI video output, including MacBook connectivity
  • VESA and CEA compliant
  • Multimedia design, multimedia post-production and video editing using Mac or PC computers
  • High resolution medical imaging and health care display, such as MRI and X-ray display
  • Stock trading stations with dual displays
  • Great for PC test/burn-in computer control, saving desk space required for multiple monitors, keyboards and mice
  • Dual system control for a single workstation increasing productivity in the office
  • Leverage DisplayPort's high resolution capabilities for Satellite Topography equipment
  • Perfect for high-res digital signage server control, simplifying access to multiple systems

Specifications

Hardware Audio: Yes
KVM Ports: 2
PC Interface: USB
PC Video Type: DisplayPort
Multi-Monitor: Yes
Connectors Console Interfaces:
2 x 0.14" (3.5 mm) mini-jack (3 position) female
2 x DisplayPort (20-pin) female
4 x USB A (4-pin) female

Host Connectors:
2 x USB B (4-pin) female
4 x 0.14" (3.5 mm) mini-jack (3 position) female
4 x DisplayPort (20-pin) female
Performance DVI Support: Yes - Dual link
IP Control: No
Maximum Digital Resolutions: WQXGA - 2560 x 1600
Wide Screen Supported: Yes
Maximum Number of Users: 1
Port Selection Support: Push button and hotkeys
Software OS Compatibility: OS independent; no software or drivers required
LED Indicators 2 x green - on-line
2 x red - selected PC
Power Power Adapter Included: Yes
Input Voltage: 110 ~ 240 AC
Input Current: 0.8 A
Output Voltage: 12 DC
Output Current: 1.5 A
Centre Tip Polarity: Positive
Plug Type: M
Certifications COE, FCC, RoHS
Environmental
Operating Temperature 32 to 104°F (0 to 40°C)
Storage Temperature -4 to 140°F (20 to 60°C)
Humidity 0 ~ 80% RH
Physical Characteristics
Colour Black
Enclosure Type Steel
Dimensions (WxHxD) 6.3 x 2.3 x 3.9" (161 x 57.5 x 100 mm)
Weight 42.4 oz (1200 g)

In The Box

  • StarTech 2-Port Dual DisplayPort USB KVM Switch with Audio & USB 2.0 Hub
  • Power Adapter
