StarTech 4-Port PCI Express USB 3.0 Card
this item may be nonreturnable
Features
- Fits standard or small form-factor computers
- Data transfer rates up to 5 Gbps plus UASP support
- Backward compatible with USB 2.0 and 1.x devices
- Built-in optional SATA power connector
- PCIe x1 interface
Related Products
Description
This StarTech 4-Port PCI Express USB 3.0 Card gives you three external ports and one internal port, for the ultimate connection flexibility.
Key Features:
Enjoy convenient USB 3.0 port availability
With three external USB 3.0 ports you can connect more devices to your computer. The card provides easy access to commonly-used peripherals such as your tablet and external hard drive. It also features an internal USB port that lets you connect a device such as a flash drive inside your computer case, providing added security and convenience.
USB 3.0 gives you fast access to your files with data transfer rates up to 5 Gbps. Plus it's backward compatible with USB 2.0 and 1.x devices, which eliminates the cost and aggravation of upgrading your existing devices.
Get up and running quickly
Setup is a breeze with native operating system support. The USB 3.0 adapter card automatically installs in Windows® 8.1, 8 and 7.
For convenient installation, this PCI Express USB 3.0 card features a dual-profile design that can be installed in almost any type of computer. It comes equipped with a standard profile bracket and also includes a low-profile bracket for installation in small form-factor/half-height systems.
UASP support for more efficient data transfers
This high-performance USB 3.0 card is enhanced with UASP support, which can perform ~70% faster read speed and ~40% faster write speed over traditional USB 3.0, when paired with UASP-enabled enclosure.
Specifications
| Connector | |
| 1 - Connector Type(s) | PCI Express x1 |
| 1 - Internal Ports | SATA Power (15 pin) |
| 3 - External Ports | USB Type-A (9 pin) USB 3.0 (5 Gbps) |
| 1 - Internal Ports | USB Type-A (9 pin) USB 3.0 (5 Gbps) |
| Environmental | |
| Operating Temperature | 5°C to 50°C (41°F to 122°F) |
| Storage Temperature | -20°C to 60°C (-4°F to 140°F) |
| Humidity | 20~80% RH |
| Hardware | |
| Ports | 4 |
| Interface | USB 3.0 |
| Bus Type | PCI Express |
| Card Type | Standard Profile (LP bracket incl.) |
| Port Style | Integrated on Card |
| Industry Standards | USB 3.0 Specification Rev. 1.0 |
| PCI Express Base Specification Rev. 2.0 | |
| Intel xHCI Specification Rev. 1.0 | |
| Chipset ID | VIA/VLI - VL805 |
| Packaging Information | |
| Package Height | 1.2 in [30 mm] |
| Package Length | 5.7 in [14.4 cm] |
| Shipping (Package) Weight | 5.0 oz [141 g] |
| Package Width | 6.7 in [17.1 cm] |
| Performance | |
| Maximum Data Transfer Rate | 5 Gbps |
| Maximum Cable Length | 9.8 ft [3 m] |
| Type and Rate | USB 3.0 - 5 Gbit/s |
| UASP Support | Yes |
| MTBF | 24,000 hours |
| Physical Characteristics | |
| Weight of Product | 1.9 oz [55 g] |
| Material | Steel |
| Product Length | 3.4 in [87 mm] |
| Product Width | 0.7 in [19 mm] |
| Product Height | 4.7 in [12 cm] |
In The Box
- 4 Port PCI Express USB 3.0 Card
- Low-Profile Bracket
- Driver CD
- Instruction Manua
