StarTech HDMI Audio Extractor - 1080p
this item may be nonreturnable
Features
- Extracts analog and digital audio
- Discreet installation with small footprint
- Supports resolutions up to 1080p
- HDCP compliant
- USB-powered
Related Products
Description
This StarTech HDMI Audio Extractor - 1080p lets you separate stereo audio from your HDMI video signal and connect it to a 3.5mm audio device, such as your stereo sound system or desktop speakers. You can also extract the audio from the HDMI signal and integrate it into an optical TOSLINK® application, using the included digital SPDIF adapter.
Key Features:
- Easily integrates the audio from your HDMI source with equipment that doesn't support HDMI
- Extracts analog and digital audio with an included 3.5mm to SPDIF adapter
- Expand the capabilities of the audio extractor by converting to RCA audio, using an inexpensive 3.5mm to RCA adapter (sold separately)
- Discreet installation with small footprint
- Supports resolutions up to 1080p with HDMI pass-through
- HDCP compliant
- USB-powered
Hassle-free integration
Your latest consumer A/V equipment probably only offers an HDMI output. This can make it difficult to integrate devices, such as your new Blu-ray™ player or computer system, with your existing audio equipment or desktop speakers.
The HDMI audio extractor is USB powered using the included power cable, for easy integration with your computer systems. The adapter also features a small footprint that discreetly blends into your hardware setup, for a uniform look.
Versatile connection options
With a 3.5mm audio output and a TOSLINK adapter included, the HDMI audio extractor lets you output audio to virtually any non-HDMI equipment, whether it's digital or analog. This makes the audio extractor great for any application where you need to connect your HDMI source to speakers that don't have an HDMI input - such as desktop speakers, or a classroom or boardroom sound system.
Maximum compatibility
The audio extractor is HDCP enabled and HDMI 1.3b compliant, to ensure compatibility with your HDMI device. Plus, the HDMI output supports resolutions up to 1920x1080 (1080p) at 60Hz, to fit any HD application.
The HDMI audio extractor can also be used with an inexpensive (sold separately) to integrate the audio from your HDMI source into 2-channel RCA audio applications.
Specifications
Connector(s) | |
1 - Connector Type(s) | USB Mini-B (5 pin) |
1 - Connector A | HDMI (19 pin) |
1 - Connector B | 3.5 mm Mini-Jack (3 Position) |
HDMI (19 pin) | |
Environmental | |
Operating Temperature | 0°C to 70°C (32°F to 158°F) |
Storage Temperature | -10°C to 80°C (14°F to 176°F) |
Humidity | 5% to 95% non-condensing |
Hardware | |
AV Input | HDMI |
AV Output | 3.5 mm Audio |
Audio | Yes |
Chipset ID | Explore - EP93Z3E |
Packaging Information | |
Package Height | 1.3 in [32.0 mm] |
Package Length | 5.6 in [14.3 cm] |
Shipping (Package) Weight | 4.8 oz [135.0 g] |
Package Width | 6.7 in [17.0 cm] |
Performance | |
Maximum Digital Resolutions | 1080p (1920 x 1080) |
Supported Resolutions | Up to 1080p (1920 x 1080) |
Wide Screen Supported | Yes |
Audio Specifications | 2.1 stereo audio |
In The Box
- HDMI audio extractor
- 5 ft. [780 mm] USB power cable
- Toslink adapter
Reviews
(no ratings yet)Give it a quick rating:
Thanks for your rating!
Write a review
Details
- Product: StarTech HDMI Audio Extractor - 1080p
- Manufacturer: Startech
- Model: HD2A
- SKU: HD2A
- RM Product #: 82232
