StarTech Mini PCIe Gigabit Network Adapter Card
this item may be nonreturnable
Features
- Jumbo Frame support up to 9k
- IEEE 802.1Q VLAN Tagging support
- Supports Full and Half duplex operating modes
- IEEE 802.3x Full Duplex Flow Control support
- Includes Full and Low Profile installation brackets
Related Products
Description
The StarTech Mini PCIe Gigabit Network Adapter Card adds 1000Mbps network connectivity to a Mini PCI Express (PCI Express Mini Card, Mini PCIe) enabled computer system, such as Mini-ITX motherboards.
Supporting features such as NDIS5 checksum and large send offload for lower CPU utilization, Wake-on-LAN (WOL) and Remote Wake-up power management, jumbo frames and VLAN tagging, this Mini PCI Express Gigabit Adapter is ready to handle a wide variety of scenarios.
Perfect for small form factor or embedded systems that originally lack Gigabit networking capability, or for adding a network connection without taking up a full-sized PCI Express slots, this high quality Mini PCIe Network Adapter includes a low profile/half-height bracket for additional installation options.
Key Features:
- Gallery (6)
- One 10/100/1000Mbps compatible RJ-45 Ethernet port
- Fully complaint with IEEE 802.3, 802.3u, and 802.3ab specifications for 10/100/1000 Mbps connections
- Jumbo Frame support up to 9k
- Crossover Detection & Auto-Correction (Auto MDIX)
- IEEE 802.1Q VLAN Tagging support
- Supports Wake-on-LAN (WOL) and Remote Wake-up Support, Pair Swap/Polarity/Skew Correction
- Microsoft® NDIS5 Checksum Offload (IPv4, TCP, UDP) and Large Send Offload support
- Supports Full and Half duplex operating modes
- IEEE 802.3x Full Duplex Flow Control support
- Compliant with PCI Express Mini Card specification 1.1
- Includes Full and Low Profile installation brackets
Specifications
| Connector | |
| Connector Type(s) | 1 - Mini PCI Express x1 (52 pin) |
| External Ports | 1 - RJ-45 |
| Environmental | |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Storage Temperature | -20°C to 85°C (-4°F to 185°F) |
| Humidity | 5% ~ 95% RH |
| Hardware | |
| Ports | 1 |
| Interface | RJ45 (Gigabit Ethernet) |
| Bus Type | Mini PCI Express |
| Card Type | Embedded |
| Industry Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| Chipset ID | Realtek - RTL8111E |
| Indicators | |
| LED Indicators | 1 - Link |
| 1 - Activity | |
| Packaging Information | |
| Package Height | 1.3 in [32 mm] |
| Package Length | 6.9 in [17.5 cm] |
| Package Width | 5.7 in [14.4 cm] |
| Package Quantity | 1 |
| Shipping (Package) Weight | 0.3 lb [0.2 kg] |
| Performance | |
| Compatible Networks | 10/100/1000 Mbps |
| Auto MDIX | Yes |
| Full Duplex Support | Yes |
| Promiscuous Mode | Yes |
| MTBF | 482765 Hours |
In The Box
- StarTech Mini PCIe Gigabit Network Adapter Card
