StarTech Multiport Adapter - USB-C to HDMI and VGA
this item may be nonreturnable
Features
- Connect to an external monitor
- Connect USB devices
- SD/microSD card access
- Easy portability
Related Products
Description
Turn your USB-C™ equipped laptop into a mobile workstation. This sleek, compact StarTech Multiport Adapter - USB-C to HDMI and VGA makes it easy to connect your MacBook Pro or Windows laptop to an HDMI or VGA monitor. Power through your workday, with three USB 3.0 (Type-A) ports with Fast-Charge support, SD™ and microSD™ card slots, and a Gigabit Ethernet port.
Key Features:
- 8-IN-1 USB-C PORTABLE MINI DOCK: Eliminates the hassle of carrying multiple adapters w/ 4K 30Hz HDMI or 1080p VGA video, 3x 5Gbps USB-A, SD slot, microSD slot, 1x Gigabit Ethernet
- POWER FLEXIBILITY: Travel dock is USB bus powered and supports up to 100W Power Delivery 3.0 Passthrough; 15W reserved for dock and up to 85W for laptop charging using your USB-C power adapter
- SIMULTANEOUS SD & MICRO SD ACCESS: USB-C multiport adapter provides both a SD/SDHC/SDXC and a MicroSD card reader for additional data storage or backup, and provides access to both simultaneously
- FAST CHARGE PORTS: Portable docking station w/3x USB 3.0 Type-A ports support BC 1.2 1.5A fast-charge to charge tablets or smartphones on any one of the ports, w/USB-C power adapter & laptop connected
- WIDE DEVICE & OS COMPATIBILITY: All-in-one adapter dongle works with HP, Dell, Lenovo, MacBook, iPad Pro, Surface, Chromebooks & Samsung Galaxy devices on Windows, macOS, Chrome OS, iPadOS & Android
Connect to an external monitor
The universal USB Type-C™ multiport adapter (Thunderbolt 3 port compatible) offers enhanced productivity in the boardroom or classroom. Connect your laptop to one external monitor:
- 4K HDMI (3840 x 2160p @ 30Hz) or VGA (1920 x 1200 @ 60Hz)
Charge your laptop and peripherals
With support for USB Power Delivery 3.0 (up to 85W), the USB-C multiport adapter lets you power and charge your laptop, and power your peripherals at the same time. PD 3.0 features Fast Role Swap to prevent USB data disruption when switching power sources (bus power and USB-C power adapter).
Connect USB devices
Connect your USB devices using the three USB 3.0 (Type-A) ports. Each USB port is a fast-charge and sync port, to ensure your tablet and smartphone are charged and ready. Each port offers 7.5W of charging power, with a combined total of 10W with all three ports in use.
SD/microSD card access
Access the SD and microSD slots at the same time, and easily move data from one card to the other.
Easy portability
For mobile use, the USB-C adapter is bus-powered and lightweight, with a wraparound USB-C cable.
Specifications
| Connector | |
| 1 - Connector Type(s) | HDMI (19 pin) |
| VGA (15 pin, High Density D-Sub) | |
| 3 - Connector Type(s) | USB 3.0 A (Fast-Charge, 9 pin) |
| 1 - Connector Type(s) | RJ-45 |
| SD / MMC Slot | |
| MicroSD | |
| USB-C (24 pin) USB Power Delivery only | |
| USB Type-C (24 pin) USB 3.0 (5Gbps) | |
| Environmental | |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Storage Temperature | -10°C to 70°C (14°F to 158°F) |
| Humidity | 10%-85%RH |
| Hardware | |
| 4K Support | Yes |
| Fast-Charge Port(s) | Yes |
| Displays Supported | 1 |
| Bus Type | USB-C |
| Industry Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| USB 3.0 - Backward compatible with USB 2.0 and 1.1 | |
| Chipset ID | VIA/VLI - VL102 |
| VIA/VLI - VL817 | |
| Parade - PS8338B | |
| Parade - PS176 | |
| Analogix - ANX9833 | |
| ALCOR MICRO - AU84612 | |
| Realtek - RTL8153 | |
| Packaging Information | |
| Shipping (Package) Weight | 4.8 oz [137.0 g] |
| Package Length | 5.6 in [14.2 cm] |
| Package Width | 6.7 in [17.0 cm] |
| Package Height | 1.2 in [30.0 mm] |
| Performance | |
| Maximum Data Transfer Rate | 5 Gbps (USB 3.0) |
| 2 Gbps (Ethernet; Full-Duplex) | |
| Maximum Analog Resolutions | 1920 x 1200p @ 60Hz (VGA) |
| Maximum Digital Resolutions | 3840 x 2160p (HDMI) @ 30Hz |
| Lower resolutions are also supported. For example, if the max is 3840 x 2160p (4K), it also supports 2560 x 1600p and 2560 x 1440p | |
| Audio Specifications | The HDMI port supports audio output |
| Type and Rate | USB 3.0 - 5 Gbit/s |
| UASP Support | Yes |
| Compatible Networks | 10/100/1000 Mbps |
| Auto MDIX | Yes |
| Full Duplex Support | Yes |
| General Specifications | With support for USB Power Delivery 3.0, the multiport adapter will power and charge your laptop, and power your peripherals at the same time, providing up to 85W of charging power, when using a 100W power adapter. Charging power will be less when using a lower-wattage power adapter. |
| Supports Fast Role Swap of PD 3.0, to ensure the connected devices will not be disconnected when your power adapter is disconnected from the multiport adapter. | |
| Each USB 3.0 port provides up to 7.5W of charging power, with a combined total of 10W when all 3 ports are in use. The charge provided depends on the number of devices connected and the amount of current each device draws. | |
| Each one of the three USB 3.0 (Type A) ports is also a fast-charge and sync port to charge your tablet or smartphone. Only one fast-charge port can be used at a time. | |
| Physical Characteristics | |
| Color | Black |
| Material | Plastic |
| Cable Length | 4.6 in [11.8 cm] |
| Product Length | 4.8 in [12.2 cm] |
| Product Width | 2.8 in [70.0 mm] |
| Product Height | 0.6 in [14.0 mm] |
| Weight of Product | 4.6 oz [129.0 g] |
| Power | |
| Power Source | USB-Powered |
In The Box
- StarTech Multiport Adapter - USB-C to HDMI and VGA
Reviews
(no ratings yet)Give it a quick rating:
Thanks for your rating!
Write a review
Details
- Product: StarTech Multiport Adapter - USB-C to HDMI and VGA
- Manufacturer: Startech
- Model: DKT30CHVSCPD
- SKU: DKT30CHVSCPD
- RM Product #: 84624
