StarTech Thunderbolt 3 PCIe Expansion Chassis
Features
- Daisy chain up to six Thunderbolt 3 devices
- Supports 5K Thunderbolt displays
- Provides a x16 4 lane PCIe 3.0 slot or interface
- Durable aluminum construction
- Works on Mac and Windows® computers
Related Products
Description
This StarTech Thunderbolt 3 PCIe Expansion Chassis lets you add a PCI Express card to your laptop or desktop computer, through an external Thunderbolt 3 connection. The chassis also features a DisplayPort video output, so you can connect an additional monitor to your laptop, and supports Thunderbolt 3 daisy chaining, so you can expand your workstation even further.
Key Features:
- TAA Compliant
- Increased productivity with Thunderbolt 3 and up to 40Gbps bandwidth — twice the speed of Thunderbolt 2 (20Gbps) and eight times faster than USB 3.0 (5Gbps)
- Supports one 4K DisplayPort monitor, and a second extended monitor display through the Thunderbolt 3 (USB-C) port
- Daisy chain up to six Thunderbolt 3 devices
- Supports 5K Thunderbolt displays
- Supports half-length and dual-slot PCIe card standards at all heights, with standard profile slot brackets
- Provides a x16 4 lane PCIe 3.0 slot or interface
- Durable aluminum construction
- Works on Mac and Windows® computers
- Internal 60 mm cooling fan
Expand the capabilities of your Thunderbolt 3 computer
The Thunderbolt 3 PCIe chassis makes it easy to expand your system with the capabilities you need to work at peak productivity. You can add many types of PCI Express cards, such as a PCIe USB 3.1/3.0/2.0 and USB-C, SSD, network, eSATA, FireWire or video capture cards. And, with the speed and bandwidth support of Thunderbolt 3 and PCIe 3.0, you can enjoy many of the same port additions you would from the PCI Express expansion slots of a desktop system.
Extend your workstation
The external PCIe enclosure features a dedicated DisplayPort output that lets you add an additional display to your laptop or desktop computer. The enclosure features a second Thunderbolt 3 (USB-C) port, that you can use to connect a secondary display (a USB-C video adapter may be required). With multiple extended displays, you can work more efficiently by multitasking faster, and avoid the hassle of continually repositioning several open windows or programs.
You can also use the second Thunderbolt 3 port to connect additional Thunderbolt, USB and DisplayPort devices to your system. You can daisy chain up to six Thunderbolt 3 devices and expand your workstation to suit your specific requirements.
Increase productivity with faster speeds
Thunderbolt 3 is the fastest connection available, which means you don’t have to deal with the performance bottlenecks of a slower connection, and can accomplish more in the same amount of time.
At up to 40Gbps this Thunderbolt 3 expansion chassis gives you the throughput to add displays to your laptop, access files quickly, and work without disruptions. It’s easy to access and edit large uncompressed files such as videos and images on the fly, making it ideal for dynamic on-site production.
Specifications
Connector | |
1 - Internal Ports | PCI Express x16 |
2 - External Ports | Thunderbolt™ 3 USB-C (24-pin) (40Gbps) |
1 - External Ports | DisplayPort (20 pin) |
Environmental | |
Operating Temperature | 5°C to 35°C (41°F to 95°F) |
Storage Temperature | -20°C to 50°C (-4°F to 122°F) |
Humidity | 20-80%RH |
Hardware | |
Fan(s) | Yes |
1 - Fans | 60 mm |
Ports | 3 |
Air Flow Rate | 14.06 CFM |
Noise Level | 24.55 dB |
Interface | Thunderbolt |
Bus Type | Thunderbolt 3 |
Card Type | Standard Profile |
Industry Standards | Thunderbolt 3 |
Fan Bearing Type | Sleeve Bearing |
Chipset ID | Intel - Alpine Ridge DSL6540 |
Indicators | |
1 - LED Indicators | Power(Blue) |
Packaging Information | |
Shipping (Package) Weight | 6,9 lb [3,1 kg] |
Package Length | 14,2 in [36 cm] |
Package Width | 11,4 in [29 cm] |
Package Height | 5,7 in [14,5 cm] |
Performance | |
Maximum Data Transfer Rate | 40 Gbps (Thunderbolt 3) |
Bandwidth | 3.94 GB/s (x4 PCIe 3.0 ) |
Type and Rate | Thunderbolt 3 - 40 Gbit/s |
Physical Characteristics | |
Color | Black |
Material | Aluminum and Steel |
Cable Length | 19,7 in [50 cm] |
Product Length | 11,0 in [28 cm] |
Product Width | 5,6 in [14,2 cm] |
Product Height | 3,2 in [82 mm] |
Weight of Product | 3,6 lb [1,6 kg] |
Power | |
Power Source | AC Adapter Included |
Input Voltage | 100 - 240 AC |
Input Current | 2A |
Output Voltage | 12V DC |
Output Current | 5.417A |
Center Tip Polarity | Positive |
Plug Type | N |
Power Consumption (In Watts) | 65 |
In The Box
- Thunderbolt 3 PCIe expansion box
- Thunderbolt 3 cable
- 4 x rubber feet
- universal power adapter (NA/JP, UK, EU, ANZ)
- quick-start guide
Reviews
(no ratings yet)Give it a quick rating:
Thanks for your rating!
Write a review
Details
- Product: StarTech Thunderbolt 3 PCIe Expansion Chassis
- Manufacturer: Startech
- Model: TB31PCIEX16
- SKU: TB31PCIEX16
- RM Product #: 84203
