| Imaging |
|
|
| Image Sensor |
1/2.3"-Type CMOS |
|
| Sensor Resolution |
Actual: 21.14 Megapixel
Effective: 8.29 Megapixel (3840 x 2160)
Actual: 21.14 Megapixel
Effective: 7.88 Megapixel (3744 x 2104) |
|
| IR Cut Filter |
No |
|
| Focus Control |
Autofocus
Manual Focus |
|
| Exposure Control |
|
|
| Shutter Speed |
1/3 to 1/2000 Second |
|
| Minimum Illumination |
3 Lux at 1/60 Shutter Speed
1.5 Lux at 1/30 Shutter Speed |
|
| Flip / Mirror Support |
Image Flip, Mirror (Vertical) |
|
| White Balance |
Range: 2000 to 15,000K
Presets: AWB, Daylight, Manual, Set A, Set B, Tungsten |
|
| Lens |
|
|
| Focal Length |
3.7 to 73.4mm (35mm Equivalent: 29.3 to 601mm) |
|
| Max Optical Zoom |
20x |
|
| Max Digital Zoom |
20x ( in UHD 4K)
40x ( in 1080p) |
|
| Field of View |
Horizontal: 63.3 to 3.5°
Vertical: 38.9 to 2°
Horizontal: 65.6 to 3.6°
Vertical: 39.8 to 2° |
|
| Maximum Aperture |
f/1.8 to 2.8 |
|
| Minimum Focus Distance |
0.4" / 1 cm (Wide) to 23.6" / 60 cm (Telae) |
|
| Video Capture |
|
|
| Video Output |
4:2:0 8-Bit via RJ45
3840 x 2160 at 5/5.99/11.99/12.50/14.99/23.98/25/29.97/50/59.94 fps
1920 x 1080 at 5/5.99/11.99/12.50/14.99/23.98/25/29.97/50/59.94 fps
1280 x 720 at 5/5.99/11.99/12.50/14.99/23.98/25/29.97/50/59.94 fps
640 x 360 at 5/5.99/11.99/12.50/14.99/23.98/25/29.97/50/59.94 fps
4:2:2 10-Bit via HDMI
3840 x 2160 at 23.98/25/29.97 fps
1920 x 1080p at 23.98/25/29.97/50/59.94 fps
1920 x 1080i at 50/59.94 fps
1280 x 720 at 50/59.94 fps
720 x 576 at 50 fps
720 x 480 at 59.94 fps
4:2:2 10-Bit via SDI/BNC
1920 x 1080p at 23.98/25/29.97/50/59.94 fps
1920 x 1080i at 50/59.94 fps
1280 x 720 at 50/59.94 fps |
|
| Embedded Audio |
HDMI/IP/NDI/SDI |
|
| Audio Recording |
Yes |
|
| Broadcast Output |
NTSC/PAL |
|
| Supported Protocols |
Camera Control Protocol
Canon XC/FreeD/NDI |
HX2 |
| IP Streaming |
H.264 via NDI HX/RTMP/RTMPS/RTP/RTSP/SRT
640 x 360 to 3840 x 2160 at 5.00p, 12.5p, 14.99p, 29.97p, 50p, 59.94p |
|
| Control |
|
|
| Presets |
100 via IP, IR, RS-422 |
|
| Pan/Tilt |
Pan: 340° (-170 to 170°) at 0.1 to 200°/s
Tilt: 130° (-30 to 100°) at 0.1 to 180°/s |
|
| Tally Light |
Yes |
|
| Interface |
|
|
| Video I/O |
1x BNC (3G-SDI) Output
1x HDMI Output
1x RJ45 (NDI) Output |
|
| Audio I/O |
1x 1/8" / 3.5 mm TRS Stereo Microphone Input |
|
| Other I/O |
1x RJ45 (RS-422) Control
1x USB-C
1x BNC (Timecode) (Shared with Video Output) |
|
| Built-In Microphone |
No |
|
| Built-In Speaker |
No |
|
| Power |
|
|
| PoE Support |
PoE++ 802.3bt |
|
| Power I/O |
1x Barrel (12VDC) Input |
|
| Power Consumption |
PoE: 26.1 W
Device: 24 VDC 23.6 W |
|
| Environmental |
|
|
| Operating Conditions |
32 to 104°F / 0 to 40°C at 10 to 90% Humidity |
|
| Storage Conditions |
32 to 104°F / 0 to 40°C at 10 to 90% Humidity |
|
| Impact Resistance |
No |
|
| Environmental Resistance |
No |
|
| General |
|
|
| Mounting |
1x 1/4"-20 Female for Tripod |
|
| OS Compatibility |
Computer: Windows 10 or Later / macOS 11 Only
Mobile: Android/iOS |
|
| Dimensions (W x H x D) |
8.7 x 7.6 x 6.9" / 220 x 194 x 176 mm (Without Protrusions) |
|
| Weight |
6.6 lb / 3 kg (Body Only) |
|
