BLUETTI RV5 + B4810 + EPANEL + EPAD Combo

Product #126286 | SKU RV5-COMBO1 | BLUETTI
Usually ships in 1 - 2 weeks what does this mean?
Our Price $8,449
Usually ships in 1 - 2 weeks what does this mean?
- +

Email me when stock arrives

Shipping & Availability
Usually ships in 1 - 2 weeks. Deliver to Auckland for $107 Change location
Click & Collect Availability
Wellington Out of stock. Pickup in 1 - 2 weeks
Click & Collect

Features

  • 5,000W powers multiple appliances simultaneously
  • LiFePO4 battery lasts 6,000+ cycles
  • Charge via solar, vehicle, shore
  • Plug-and-play setup for any user
  • Quiet, generator-free, low-maintenance power
  • UL-certified, IP65, app-controlled confidence

Description

With 5,000 W of continuous power, the RV5 lets you run your A/C, microwave, coffee maker, and more all at once, just like at home. Powered by B4810 LiFePO₄ batteries, it gives you over 6,000 charge cycles for years of reliable energy. Even in the cold, the self-heating feature keeps things running smoothly. At only 7 W of standby power, each charge goes further. The RV5 lets you live fully, with peace of mind, and enjoy every moment of your journey without worrying about power.

Fast, Flexible Charging for Non-Stop Adventure.

Adventure doesn't stop for charging, and now you don't have to either. The RV5 keeps you powered with fast, versatile charging options. Recharge quickly with up to 5,000 W of shore power at the campsite, capture up to 1,800 W from the sun while boondocking, or harness up to 1,200 W from your vehicle's alternator while on the road. Focus on the journey, not the charge.

The 1-Day RV Upgrade. No Electrical Degree Required.

Transform your RV's power in just one weekend. Our plug-and-play system eliminates compatibility hassles and the guesswork of traditional builds. Simplicity doesn't mean you're on your own. From planning to final connections, our team of experts is here to guide you every step of the way, making your DIY upgrade a breeze.

True Tranquility, Powered by Safety.

Escape the noise of traditional generators and embrace the peace of nature. True tranquility isn't just about silence; it's about knowing you're safe. With advanced LiFePO4 battery technology and UL certification, the RV5 ensures your family, pets, and home on wheels are always protected. Enjoy worry-free, uninterrupted power, backed by the highest standards of safety and reliability.

Specifications

BLUETTI RV5
Input
Input Voltage 230 V
Shore Power/Generator Charging 5,000 W Max. (limited by battery terminal current)
AC Output
AC Rated Output Voltage 230 V
AC Rated Output Power 5,000 W
Solar Charging (PV1/PV2)
Solar Charging (PV1/PV2) Max. Input Power 1,800 W
Solar Charging (PV1/PV2) Input Voltage 12 V to 50 V
Solar Charging (PV1/PV2) Max. Input Current 50 A
Vehicle Charging (PV2)
Vehicle Charging (PV2) Max. Input Power 600 W (12 V) / 1,200 W (24 V)
Vehicle Charging (PV2) Input Voltage 12 V to 14.4 V (12 V)
24 V to 28.8 V (24 V)
Vehicle Charging (PV2) Max. Input Current 50 A
DC Output
DC Rated Output Voltage 12 V/24 V
DC Rated Output Current 100 A (12 V)
60 A (24 V)
DC Rated Output Power 1,360 W (12 V)
1,620 W (24 V)
Total DC Load Power 6,000 W Max. (varies by battery type and quantity)
General
Weight Approx. 30.86 lbs/14 kg
Dimensions (L x W x D) 17.72 × 19.69 × 6.30 in/450 × 500 × 159.9 mm
Operating Temperature −4°F to 131°F/−20°C to 55°C
Storage Temperature −4°F to 104°F/−20°C to 70°C
Operating Humidity 95% Max.
Uninterruptible Power Supply (UPS) Switchover time ≤20ms
BLUETTI B4810
Battery
Capacity 5,120 Wh (51.2 V, 100 Ah)
Type LiFePO₄ (Lithium Iron Phosphate)
Life Cycles 6,000 Cycles @ 70% Capacity
Charging & Discharging
Charge Current 50 A (Recommended)
100A Max.
Discharge Current 100A Max.
Peak Discharge Current 200A @ 30s
Cell Temperature Protection Charging: <-1°C or >61°C (<30°F or >142°F)
Discharging: <-21°C or >61°C (<-5.8°F or >142°F)
General
Net Weight Approx. 46 kg (101.4 lbs)
Dimensions (L × W × H) 608 × 380 × 145mm (23.94 × 14.96 × 5.71in)
IP Rating IP65
Max. Expansion (Parallel & Series) 122.88 kWh (24P), 51.2 V, 2,400 Ah
Charging Temperature -20°C to 55°C (-4°F to 131°F)
Discharging Temperature -20°C to 55°C (-4°F to 131°F)
Storage Temperature Up to 1 Month: -20°C to 40°C (-4°F to 104°F)
Up to 6 Months: -20°C to 25°C (-4°F to 77°F)

In The Box

  • RV5 All-in-One Power Hub
  • E-Panel
  • E-Pad
  • B4810 battery
  • A-AKIT-UN-0406 cable
  • A-AKIT-UN-0407 cable
  • A-AKIT-UN-PANEL cable

Reviews

0.0 (no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:
Write a review

Details

  • Product: BLUETTI RV5 + B4810 + EPANEL + EPAD Combo
  • Manufacturer: BLUETTI
  • Model: RV5-COMBO1
  • SKU: RV5-COMBO1
  • RM Product #: 126286
  • Battery: Lithium-Ion
