| Light |
|
| Fixture Type |
Gobo Projector / Moving Head / Spotlight |
| Light Source |
1 x White LED - 580 W / 4.2 A |
| Light Source Life Expectancy |
50,000 Hours |
| Colours |
Cyan, Magenta, Yellow, CTO (Colour Temperature Orange) |
| Photometrics |
6.8°:
6682.6 fc / 71,933 Lux at 16.4' / 5 m
54.8°:
239.7 fc / 2580 Lux at 16.4' / 5 m |
| Lumen Output |
28,000 Lumens (Output) |
| Beam Angle |
6.3 to 42.6° |
| Field Angle |
7.9 to 54.7° |
| Shutter / Strobe |
Electronic |
| Iris |
Yes, Mechanical |
| Focus |
Motorised |
| Zoom Adjustment |
Motorised, 5.5 to 58.6° |
| Dimming |
16-Bit Electronic, 0 to 100% with 5 Dimmer Modes |
| Prism |
5-Facet Linear (Rotating) |
| Performance |
|
| Operating Modes |
Colour Change, Colour Dimmer, DMX, Move-in-Black, Programme, Totem |
| Macros / Programmes |
None |
| Effects |
Colour Scroll
Colour Split
Gobo Scroll
Gobo Shake
Strobe
Frost Filter
Light Beams |
| Gobos |
1 x Removable Metal Gobo
1 x Fixed Gobo |
| Movement |
|
| Tilt Ranges |
270° / 180° / 90° |
| Pan Ranges |
540° / 360° / 180° |
| Pan/Tilt Inversion |
Yes |
| Control |
|
| Control Protocols |
DMX512, W-DMX, RDM, Art-Nett, sACN |
| DMX Channel Modes |
2 Mode(s):32 / 48-Channel |
| Display / Controls |
LCD / 6-Button |
| Remote Control |
Yes |
| Mobile App Compatible |
No
*As of December, 2022: Cheque with manufacturer for the most up-to-date compatibility |
| Connectivity |
|
| Inputs/Outputs |
2 x XLR 5-Pin DMX Input/Output
2 x RJ45 DMX/Network Input/Output |
| AC Input Power |
100 to 240 VAC, 50/60 Hz |
| AC Power Connector |
Input: 1 x Seetronic IP-Rated
Output: None
Plug Type: NEMA 1-15
|
| Power / Current Consumption |
100 VAC, 60 Hz: 800 W / 8.2 A
120 VAC, 60 Hz: 800 W / 6.82 A
208 VAC, 60 Hz: 779 W / 3.77 A
230 VAC, 50 Hz: 763 W / 3.41 A
240 VAC, 50 Hz: 767 W / 3.34 A |
| Power Linking |
None |
| Environmental |
|
| IP Rating |
IP65 |
| Environmental Protection |
Advertised as Weather Resistant
*Manufacturer Testing: IP65 |
| Physical |
|
| Mounting |
Omega Bracket |
| Included Accessories |
1 x Power Cable |
| Duty Cycle |
None |
| Exterior Colour |
Black |
| Cooling |
Fan (Variable Speed), Forced Convection |
| Dimensions |
27.52 x 15.28 x 9.92" / 69.9 x 38.81 x 25.2 cm |
| Weight |
67 lb / 30.4 kg |
