| Light |
|
| Fixture Type |
Gobo Projector / Moving Head / Spotlight |
| Light Source |
1 x White LED - 1250 W / 4 A |
| Light Source Life Expectancy |
50,000 Hours |
| Colours |
CTO (Colour Temperature Orange), Cyan, Magenta, Yellow |
| Photometrics |
6.2°:
11,813.1 fc / 127,159 Lux at 16.4' / 5 m
58.3°:
373.4 fc / 4019 Lux at 16.4' / 5 m |
| Colour Temperature |
6895K |
| Lumen Output |
94,000 Lumens (Source)
60,756 Lumens (Output) |
| Beam Angle |
6.2 to 48.7° |
| Field Angle |
8.4 to 54.1° |
| Shutter / Strobe |
Electronic |
| Iris |
Yes, Mechanical |
| Focus |
Motorised |
| Zoom Adjustment |
Motorised, 6.4 to 58.3° |
| Dimming |
16-Bit Electronic, 0 to 100% with 4 Dimmer Modes |
| Prism |
5-Facet Linear (Rotating)
5-Facet Circular (Rotating) |
| Performance |
|
| Operating Modes |
Colour Change, Colour Dimmer, DMX, Move-in-Black, Programme, Totem |
| Macros / Programmes |
3 x Auto-Programme |
| Effects |
Colour Scroll
Colour Split
Gobo Scroll
Gobo Shake
Strobe
Frost Filter
Light Beams |
| Strobe Rate |
0 to 20 Hz |
| Gobos |
2 x Removable Glass Spot/Open |
| Gobo Size |
Outer Diameter: 1.2" / 30 mm
Max Image Size: 1" / 25 mm
Max Thickness: 0" / 1.1 mm |
| Colour Accuracy Index |
CRI: 71.5 |
| Movement |
|
| Tilt Ranges |
270° / 180° / 90° |
| Pan Ranges |
540° / 360° / 180° |
| Pan/Tilt Inversion |
Yes |
| Control |
|
| Control Protocols |
DMX512, W-DMX, RDM, Art-Nett, sACN |
| DMX Channel Modes |
2 Mode(s):38 / 55-Channel |
| Display / Controls |
LCD / 6-Button |
| Remote Control |
Yes |
| Mobile App Compatible |
No
*As of December, 2022: Cheque with manufacturer for the most up-to-date compatibility |
| Connectivity |
|
| Inputs/Outputs |
2 x XLR 5-Pin DMX Input/Output
2 x RJ45 DMX/Network Input/Output |
| AC Input Power |
100 to 240 VAC, 50/60 Hz |
| AC Power Connector |
Input: 1 x Seetronic IP-Rated
Output: 1 x Seetronic IP-Rated
Plug Type: Unterminated/Bare Wire
|
| Power / Current Consumption |
1780 W / 15.07 A
1740 W / 8.7 A
1760 W / 7.79 A |
| Power Linking |
None |
| Environmental |
|
| IP Rating |
IP65 |
| Environmental Protection |
Advertised as Weather Resistant
*Manufacturer Testing: IP65 |
| Physical |
|
| Mounting |
Omega Bracket |
| Included Accessories |
1 x Power Cable |
| Duty Cycle |
None |
| Exterior Colour |
Black |
| Cooling |
Fan (Variable Speed), Forced Convection |
| Certifications |
COE, MET, FCC, CB, UKCA
*as per Manufacturer |
| Dimensions |
32.91 x 18.3 x 11.93" / 83.59 x 46.5 x 30.3 cm |
| Weight |
102.5 lb / 46.5 kg |
