Key Features:
| Specifications | |
| Interfaces | * 1x PCI Express interface * 1x Link LED * 1x Tx/Rx LED * 1x Hardware WPS button * 2x RP-SMA connector * 2x High-gain 3dBi detachable antenna |
| Standards | * IEEE 802.11b * IEEE 802.11g * IEEE 802.11n |
| Data Rates | * 11b: 1/2/5.5/11Mbps * 11g: 6/9/12/24/36/48/54Mbps * 11n (20MHz): MCS0-15 (up to 144Mbps) * 11n (40MHz): MCS0-15 (up to 300Mbps) |
| Frequency Band | 2.4000 to 2.4835GHz (Industrial Scientific Medical Band) |
| Output Power | * 11n: 12dBm±1.5dBm * 11g: 12dBm±1.5dBm * 11b: 16dBm±1.5dBm |
| Temperature | * Operating: 32°F ~ 103°F (0°C40°C) * Storage: -4°F149°F (-20°C~65°C) |
| Wireless Security | * 64/128-bit WEP, WPA, WPA2 & IEEE 802.1x * Hardware & Software WPS configuration |
| Installation | Multi-language EZmax Setup Wizard |
| Humidity | * Operating: 10% - 90% (non-condensing) * Storage: max. 95% (non-condensing) |
| System Requirements | Windows/XP/Vista/7/8 |
| Dimensions | 22 x 121 x 88mm (without antenna) |
| Certifications | CE, FCC |
