FeelWorld NDI20X NDI PoE PTZ Camera with 20x Optical Zoom
Usually ships in 3 - 4 weeks
Our Price
$1,879.00
Usually ships in 3 - 4 weeks
Email me when stock arrives
Shipping & Availability
Usually ships in 3 - 4 weeks.
Deliver to
Auckland
for $14.00
Change location
Click & Collect Availability
Wellington
Out of stock.
Pickup in
3 - 4 weeks
Click & Collect
Related Products
Features
- 1/2.9" 2.07MP CMOS Sensor
- Simultaneous 3G-SDI, HDMI & NDI|HX Out
- Supports up to 1080p60 Video
- 20x Optical Zoom, 3.3 to 54.7° FOV
- ±170° Pan, -30 to 90° Tilt Range
- PoE Support
Description
Simultaneously stream your content to several platforms using the FeelWorld NDI20X NDI PoE PTZ Camera with 20x Zoom. Ideal for video conferencing, live events, and houses of worship, this camera features a 1/2.9" CMOS sensor, both HDMI and 3G-SDI outputs, and audio input. NDI|HX streaming protocols and PoE (Power-over-Ethernet) are supported over a single cable, saving both cost and time.
The camera uses H.264 and H.265 compression formats and offers low-light correction and autofocus functions. You can save 10 presets using the included remote control or up to 255 presets via the WEBSERVER software.
Specifications
Image Sensor
| Image Sensor | 1-Chip 1/2.9" CMOS Sensor |
| Sensor Resolution | Effective: 2.07 Megapixel |
| Signal-to-Noise Ratio | 55 dB |
| Minimum Illumination | 0.5 Lux |
| White Balance | 3000 to 6500K |
Camera
| Built-In ND Filter | None |
| Flip / Mirror Support | Image Flip |
Lens
| Optical Zoom Ratio | 20x |
| Focal Length | 5.5 to 110mm |
| Field of View | Horizontal: 3.3 to 54.7° |
| Maximum Aperture | f/1.6 to 3.5 |
| Focus Control | Autofocus <br / > Manual Focus |
Video Output
| Output Formats | SDI, HDMI, RJ45: 1920 x 1080p at 25, 29.97, 30, 50, 59.94, 60 fps 1280 x 720p at 25, 29.97, 30, 50, 59.94, 60 fps |
| Embedded Audio | HDMI/SDI: 2-Channel |
| IP Streaming | H.264, H.265, ONVIF, RTMP, RTSP: 1080i, 1080p, 720p |
| IP Multi-Stream Support | Yes |
Recording
| Audio Recording | None |
Control
| Presets | 255 via IP, RS-232, VISCA 10 via IR |
| Move Speed | Pan: 0.1 to 60°/sec Tilt: 0.1 to 30°/sec |
| Movement Range | Pan: 340° (-170 to 170°) Tilt: 120° (-30 to 90°) |
Interfaces
| Video Output Connectors | 1 x HDMI Type A Female 1 x BNC (3G-SDI) Female 1 x RJ45 (HX / NDI) Female |
| Audio I/O | 1 x 1/8" / 3.5 mm Stereo Line Level Input |
| Control Interface | 1 x Terminal Block (RS-485) Input <br ?> 1 x 8-Pin Mini-DIN (RS-232) |
Power
| PoE Support | Yes |
| Power Connectors | 1 x Barrel / Coaxial (12 VDC up to 1 A) |
| Power Consumption | Power Supply: 110 to 220 VAC at 2 A (12 W) |
Environmental
| Operating Temperature | -10 to 50°C |
| Storage Temperature | -40 to 70°C |
| Operating Humidity | 20 to 80% |
| Storage Humidity | 20 to 95% |
In The Box
- FeelWorld NDI20X NDI PoE PTZ Camera with 20x Optical Zoom
- Remote Control
- RS232 Control Cable
- RS485 Terminal Block
- Power Adapter
- Power Cable
- Manual
