Lilliput 7" HDMI On-Camera Monitor
Features
- 7" 800 x 480 Display
- HDMI, YPbPr, Composite Inputs
- Built-In Battery
- 140° Horizontal Viewing Angle
- Includes Ball Mount and Sun Hood
Related Products
Description
With inputs supporting analogue and digital sources, this 7" HDMI On-Camera Monitor from Lilliput provides an 800x480 pixel display for chequing your image's focus and exposure. The display's 16:9 aspect ratio fits most signals output from HD camcorders without letterboxing or pillarboxing the image, ensuring the full-screen resolution is used.
On the rear panel, the HDMI input supports DSLR cameras and newer camcorders with HDMI outputs, up to 1080p resolution. For legacy cameras and analogue equipment, a component YPbPr, as well as dual composite video BNC inputs, are also available.
For wide viewing angles and accurate colours, this monitor features an IPS display with an anti-glare finish and a 500:1 contrast ratio for punchy images. A sun hood is included for preventing excess glare when outdoors. For power, a built-in battery can provide up to 3 hours of use on a full charge. Alternatively, a 6-20 VDC power source can be input via the barrel jack. A ball mount is also included for securing the monitor atop a camera using an available shoe-mount.
Key Features:
- 7" camera-top monitor with 16:9 aspect ratio
- 500:1 contrast ratio produces vivid and rich colours
- Enhanced 450 cd/m2backlight produces a crystal clear picture and shows colours vividly
- IPS panel offers 130° horizontal and 120° vertical wide viewing angles
- Built-in 2,200mAh Li-ion battery
- Shoe mount adapter included
Specifications
| LCD Display | |
| LCD Size | 7" (18 cm) |
| Display Resolution | 800 x 480 |
| Aspect Ratio | 16:9 |
| Brightness | 450 cd/m2 |
| Contrast Ratio | 500:1 |
| Backlight | White LED |
| Surface Treatment | Anti-glare |
| Viewing Angle | 70/70° (left/right) and 50/70° (up/down) |
| Video | |
| Interface | Video, AV1, AV2, YPbPr, HDMI, DC power |
| Input Connectors | Composite (BNC), YPbPr (BNC), HDMI |
| Input Format Support | HDMI Format Support: FULL HD: 1080p (60/59.94/50) HD: 1080i (60/59.95/50), 720p (60/59.94/50) SD: 480i (60/59.94), 576i (50) |
| General | |
| Control | Basic: -Volume down,+ Volume up, menu, 2 x selection key, switch key, power Advance: Brightness, Contrast, Saturation, Tint, OSD H-Position, OSD V-Position, Reset, Colour Temperature, Red, Green, Blue, Language, Miscellaneous, Exit, Image Flip, Aspect Ratio, Sharpness, OSD duration. |
| Speaker | Built in, 1 W |
| Battery | 7.4 VDC, 2200 mAh |
| Power Consumption | Max: 8 W |
| Environmental | Operating: -20 to 60°C Storage: -30 to 70°C Operating at High Temperature and High Humidity: 60°C / 90% RH max, 240 hrs |
| Dimensions (L x W x D) | 188 x 131 x 33 mm |
| Weight | 1.3 kg |
In The Box
- Lilliput 7" HDMI On-Camera Monitor
- Remote Control
- HDMI Cable
- Shoe Mount
- Sun Shade
- DC Adapter
Reviews
(no ratings yet)Give it a quick rating:
Thanks for your rating!
Write a review
Details
- Product: Lilliput 7" HDMI On-Camera Monitor
- Manufacturer: Lilliput
- Model: 668
- SKU: 668
- RM Product #: 48203
- Screen Resolution: 800 x 480
- Display Size: 7.0 inches
- Monitor Inputs: HDMI
- Monitor Inputs: Composite
- Screen Size: 7"
- Warranty: All LILLIPUT brand products come with a one year manufacturer warranty.
