| Video Input |
HDMI input
- Port: 2x HDMI 1.4 Type-A port (HDMI 1 / HDMI 2)
- Resolution/frame rate: up to 1920x1080p, 60fps
- Color depth: 8-bit
- Color sampling: RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2
USB input
- Port: 1x USB 3.0 Type-A port (WEB CAMERA 3)
- Resolution/frame rate: up to 1920x1080p, 60fps
- Codec: YUYV, H.264, MJPEG, YU12, UYUV, NV12
Video/image file input
- Resolution: up to 4K resolution
- Codec: H.264, HEVC (H.265)
- Format: MOV/MP4/MKV video files, JPEG/PNG/BMP image files |
| Audio Input |
1x 3.5mm jack: line in port
- Format: 2-channel, 48 KHz, 16-bit
1x 3.5mm jack: headset port
- Format: 2-channel, 48 KHz, 16-bit
- Standard: CTIA
Audio from HDMI 1 port: 2-channel, 48 KHz, 16-bit
Audio from HDMI 2 port: 2-channel, 48 KHz, 16-bit
Audio from WEB CAMERA 3 port: 2-channel (The audio is disabled by default, and can be enabled on Web UI.)
Audio embedded in video files
Audio file: MP3, M4A, WAV |
| Video Output |
USB OUT
- Port: 1x USB 3.0 Type-C port
- Resolution: 1920x1080, 1280x720, 640x480
- Frame rate: 60fps, 30fps, 15fps
- Color sampling: 8-bit YUYV 4:2:2 / NV12 4:2:0 / ARGB
HDMI OUT
- Port: 1x HDMI 1.4 Type-A port
- Output image: HDMI 1, HDMI 2, or PROGRAM image
- Output resolution: configurable |
| Audio Output |
1x 3.5mm jack: headset port
- Format: 2-channel, 48 KHz, 16-bit
- Standard: CTIA
Audio output via WEB CAMERA 3 port: 2-channel (The audio is disabled by default, and can be enabled on Web UI.)
Audio output via USB OUT port: 2-channel, 48 KHz, 16-bit
Audio output via HDMI OUT port: 2-channel, 48 KHz, 16-bit |
| Video Processing & Production |
HDMI input
- Video/audio signal data: auto extracted
- Colour space/quantisation range: calibration supported
- De-interlacing: Bob, motion adaptive, motion compensated
- EDID: changeable
USB input
- Codec: configurable
- Resolution/frame rate: configurable
Frame rate/color space conversion: auto
Source switching: auto, manual
Scene compositing: picture in picture, side by side
Scene editing: crop, mirror, scale, rotate, and more
Annotation: pens, shapes, text, and more
Presentation: creation and management supported |
| Audio Processing & Production |
Resampling: auto
Audio de-embedding and embedding: auto
Volume control: supported for audio output and each audio input
Gain: supported |
| Recording and Screenshot |
Recording format: H.264 + MP4
Encoding format for recording: up to 1080p60, configurable
Screenshot format: JPEG
Storage space: 32 GB |
| Network |
Ethernet: 1x RJ45 port, 10/100/1000 Mbps Base-T
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax, Station mode and AP mode supported
USB network
- Port: USB OUT
- OS version: Windows 10 19H1 and later, macOS 10.12 and later, Linux
IP address: DHCP-assigned, static
DNS server: Auto or manual |
| Provided Software |
USB Fusion App: create, edit and control presentations
- OS version: iOS 12 and later, Android 7.0 and later
Web UI: configure and manage the device and presentations |
| Compatible Software |
Skype, Zoom, Microsoft Teams
Other UVC/UAC compliant, DirectShow/V4L2/AVFoundation compatible software |
| Compatible OS |
Windows: Windows 7 and later, Server 2008 and later (x86 & x64)
Linux: Linux system with kernel 2.6.35 or later (x86, x64 & ARM)
Mac: OS X 10.9 and later, macOS 10.12 and later |
| Buttons |
Switch and composite sources |
| LED Indicators |
Power/Wi-Fi/HDMI 1/HDMI 2/Web Camera 3 indicators
- On: connected/signal locked
- Off: not connected/signal not locked
Line-in/headset indicators
- On: connected
- Pulsing: not connected |
| Power |
Power port: 2.1mm x 5.5mm jack
Power input: 12V/3A
Max. power usage: 21.3W |
| Dimensions |
186mm x 101.2mm x 30mm |
| Accessories |
1x Power adapter (international)
1x USB 3.0 cable |
| Working Environment |
Operating temperature: 0 to 40 deg C
Storage temperature: –20 to 70 deg C
Relative Humidity: 5% to 90% non-condensing |
