Midas DL16 - 16-Input / 8-Output Stage Box with 16 Midas Mic Preamps

Product #42850 | SKU DL16 | Midas
Contact us for an ETA what does this mean?
Our Price $1,969.00
Contact us for an ETA what does this mean?
This product can't be purchased at this time, please contact us for more information.
- +

Email me when stock arrives


Features

  • 16 Midas PRO Mic Preamps with +48V
  • 8 Low Impedance Line Level Outputs
  • Ultranet Monitoring System Connectivity
  • Dual ADAT Outputs
  • Dual AES50 Ports for Cascading Units

Related Products

Behringer SD16 - I/O Stage Box with 16 Preamps Behringer SD16 - I/O Stage Box with 16 Preamps
Pro Co Sound MT8XFXM-20 Multitrack Analog Studio Harness Cable Pro Co Sound MT8XFXM-20 Multitrack Analog Studio Harness Cable
Canare Starquad XLRM-TRSM Cable (Black, 10') Canare Starquad XLRM-TRSM Cable (Black, 10')
Hosa OPM-305 Pro Fiber Optic Cable 5ft Hosa OPM-305 Pro Fiber Optic Cable 5ft
Hosa OPM-303 Pro Fiber Optic Cable 3ft Hosa OPM-303 Pro Fiber Optic Cable 3ft
Hosa MID-510 Pro MIDI Cable 10ft Hosa MID-510 Pro MIDI Cable 10ft
Hosa MID-505 Pro MIDI Cable 5ft Hosa MID-505 Pro MIDI Cable 5ft
Hosa MID-503 Pro MIDI Cable 3ft Hosa MID-503 Pro MIDI Cable 3ft
Hosa MID-202 Dual MIDI Cable 2m Hosa MID-202 Dual MIDI Cable 2m

Description

Closing the gap between stage and front of house, the Midas DL16 - 16-Input / 8-Output Stage Box with 16 Midas Mic Preamps is a 16-in/8-out stage box that includes 16 fully programmable and remotely controllable Midas mic preamps, which are the same preamps found in the larger PRO Series consoles, and are equipped with switchable +48V phantom power. Additionally, the DL16 features 8 electronically balanced low impedance line level outputs, as all of the DL16's inputs and outputs have been designed to handle both balanced and unbalanced signals, removing any worries about signal degradation, noise, and crosstalk interference. The DL16 also features dual Cirrus Logic Digital to Analogue convertors, providing a reduced noise floor and lower distortion, and post-DAC filtering to remove wide-band noise.

The DL16 Stage Box includes an Ultranet port that lets performers connect directly to the Powerplay P16 system for in-ear monitoring, and lets each artist take control of their own monitor mix. This allows for performance and audience concentration without other possible sonic distractions.

The DL16 comes outfitted with dual ADAT outputs for use in splitter mode and stand-alone digital multi-core applications. Many manufacturers have adopted the ADAT digital interface as a means of transferring digital data between certain types of audio devices, such as mixers, synthesisers, lighting rigs, and effect processors. With the DL16's dual ADAT outputs, you can simply connect to any ADAT-compatible outboard devices.

The stage box also includes dual AES50 ports for cascading multiple units over a single shielded (STP) CAT5 cable. Up to three DL16s can be daisy-chained to deliver 48 channels in and 24 out to the stage. This flexibility benefits both live and studio recording applications, as well as post-production, broadcasting, and audio routing infrastructure.

The DL16 can be remotely operated up to 328' (100 m) via CAT5/5e cable, simplifying communication between the stage and front of house. The DL16's monitoring / head amp control section allows you to select any one of the 16 inputs or 8 outputs for immediate line cheques. In addition to signal metering at the stage box, you can set individual channel gain, apply +48V phantom power, plus you have the option listening directly to the input signal. Even at this distance, all settings can be controlled or programmed from the front panel of the console. Once set, all configuration settings can be locked at the console for system security.

Each of the 16 Neutrik XLR inputs is equipped with a status indicator LED, which illuminates to show when the +48V phantom power is used, providing instant clarity and ease of use. For versatility, each headphone output is assignable to any of the inputs or outputs for on-stage monitoring via the 1/4" jack socket located on the front panel of the DL16. With this, you have the option of listening directly to any of the 16 inputs via headphones. Simply select the signal that you need to monitor by scrolling through each of the 16 channels, adjusting the gain where needed, and change the operating mode, all via a single rotary potentiometer.

The automation scenes allow MIDI to be incorporated, so that the external MIDI-compatible devices can be controlled as part of the scene change via the console's MIDI output. Additionally, console events can be triggered from an external MIDI source via the console's MIDI input. You can also control the gain and phantom power settings remotely using the MIDI communication functionality.

Housed in a road-ready, rugged 19" 2U rack-mountable chassis, the DL16 is designed to withstand the rigours of touring applications.

Key Features:

  • 16 Midas PRO microphone preamplifiers with switchable +48V phantom power
  • 8 electronically balanced low impedance line level outputs
  • Ultranet personal monitoring system connectivity for in-ear applications
  • Dual ADAT outputs for use in splitter mode and stand-alone digital multicore applications
  • Dual AES50 ports for cascading DL16 units—no merger or router required
  • Remote operation up to 328' (100m) via CAT5/5e cable
  • All settings programmable from front panel controls or console
  • Status indicator LEDs on front panel
  • Headphones output assignable to any of the inputs or outputs for on-stage monitoring
  • MIDI In/Out for bidirectional communication between FOH console and on-stage MIDI devices
  • Features Neutrik etherCON AES50 and Ultranet network ports
  • Rugged 2U rackmount chassis for durability in portable applications
  • Auto-ranging universal switch-mode power supply

Specifications

Front Panel Connections
Microphone Inputs 16 XLR male 3-pin, Neutrik
+ 48 V phantom powered
Outputs (Analogue) 8 XLR female 3-pin, Neutrik
Dual ADAT
Preamps 16 Midas PRO
MIDI I/O For directional communication
Monitoring Ultranet personal monitoring system
Headphones 1 x 1/4" (6.3 mm) TRS
Network AES ports with Klark Teknik SuperMAC technology
Network Cables CAT5/5e for up to 328' (100 m)
Power Supply Auto-ranging universal switch-mode power supply

In The Box

  • Midas DL16 - 16-Input / 8-Output Stage Box with 16 Midas Mic Preamps

Reviews

0.0 (no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:
Write a review

Details

  • Product: Midas DL16 - 16-Input / 8-Output Stage Box with 16 Midas Mic Preamps
  • Manufacturer: Midas
  • Model: DL16
  • SKU: DL16
  • RM Product #: 42850
  • Warranty: 10 year manufacturer warranty (Excluding CAT5EM which has a 1 year manufacturer warranty)
