The Neutrik NA3MP 3-Pole XLR Male to Stereo 1/4" Locking Plug Adapter is a versatile, pre-wired, and ready to use adapter for reliably interlocking various connector systems.
Key Features
- Professional look and compact space saving design, based on the X Series (XLR worldwide accepted standard)
- Rugged diecast shell for reliability
Specifications
| Contact Resistance |
Inner: ≤3 mΩ (XLR) |
| Comment |
≤6 |
| Dielectric Strength |
1.5 kVDC / >1 kVDC (XLR/Plug) |
| Insulation Resistance |
>2 GΩ |
| Locking Device |
Latch lock |
| Contact Plating |
2 µm Ag over 2 µm Ni |
| Contacts |
Brass (CuZn39Pb3) (plug) |
| Insert |
Polyamide (PA 6.6 30% GR) |
| Shell |
Zinc diecast (ZnAl4Cu1) |
| Shell Plating |
Gal Cu/Ni |
| Temperature Range |
4 to 149°F (-20 to 65°C) |
