The OWON HDS320S Digital Oscilloscope is a oscilloscope, multimeter and waveform generator. The 3.5-inch high-resolution, high-contrast color LCD display, suitable for outdoor use.
OWON HDS320S Digital Oscilloscope
In Stock with Supplier
Usually ships in 2 - 3 weeks
Our Price
$819
In Stock with Supplier
Usually ships in 2 - 3 weeks
Email me when stock arrives
Shipping & Availability
Usually ships in 2 - 3 weeks.
Deliver to
Auckland
for $4.90
Change location
Click & Collect Availability
Wellington
Out of stock.
Pickup in
2 - 3 weeks
Click & Collect
Features
- Oscilloscope + multimeter + waveform generator, multifunction in one
- 3.5-inch high-resolution, high-contrast color LCD display, suitable for outdoor use
- Self-calibration function
- SCPI supported, facilitate secondary development
Description
Specifications
| Oscilloscop Specifications | |
| Bandwidth | 200MHz |
| Channel | 2+1(signal generator) |
| Sample rate | 1GS/s |
| Acquisition model | Sample, Peak detect |
| Record length | 8K |
| Display | 3.5 inch LCD |
| Waveform refresh rate | 10000 wfrms/s |
| Input coupling | DC, AC ,Ground |
| Input impedance | 1 MΩ±2%, in parallel with 16 pF±10 pF |
| Probe attenuation | 1X,10X,100X,1000X,10000X |
| Max. input voltage | 400V (DC+AC, PK - PK) |
| Bandwidth limit(typical) | 20MHz / Full bandwidth |
| Sensitivity Resolution | 10mV/div~10V/div |
| Low Frequency（-3db） | ≥10 Hz (at input, AC coupling) |
| Rise time (at input, Typical) | ≤1.75ns |
| Trigger type | Edge |
| Trigger model | Auto, Normal, single |
| Trigger level range | ±4 div from the screen center |
| Automatic measurement | Period, Frequency, Mean, PK-PK, Max, Min，RMS、Rise Time、Fall Time、+Width、-Width |
| Cursor measurement | ΔV, ΔT, |
| Communication interface | USB Type-C |
| Multimeter Specifications | |
| Full scale reading | 4 1/2 digitals（max 20000 count） |
| Testing Modes | Voltage, Current, Resistance, Capacitance, Diode ,Continuity |
| Maximum Input Voltage | AC 750V， DC 1000V |
| Maximum Input Current | DC : 10A AC : 10A |
| Diodes Test | 0-2V |
| Waveform Generator Specifications | |
| Arbitrary Waveform | 0.1Hz~5MHz |
| Sample Rate | 125MSa/s |
| Channel | 1 |
| Amplitude | 20mVpp-5Vpp（high impedance），10mVpp-2.5Vpp (50Ω) |
| Waveform length | 8K |
| Vertical resolution | 14bits |
| Load impedance | 1MΩ/50Ω |
| Frequency Output | |
| Sine | 0.1Hz~30MHz |
| Square | 0.1Hz~6MHz |
| Ramp | 0.1Hz~1MHz |
| Pulse | 0.1Hz~5MHz |
In The Box
- OWON HDS320S Digital Oscilloscope
Reviews
(no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:Give it a quick rating:
Thanks for your rating!
Write a review
Details
- Product: OWON HDS320S Digital Oscilloscope
- Manufacturer: OWON
- Model: HDS320S
- SKU: HDS320S
- RM Product #: 114724
