| Imaging |
|
| Lens Mount |
Canon RF |
| Effective Sensor Resolution |
Effective: 32.5 Megapixel (6960 x 4640)
Actual: 34.2 Megapixel |
| Image Sensor |
35.9 x 23.9 mm (Full-Frame) CMOS |
| Sensor Crop (35mm Equivalent) |
Crop Factor: 1x
Additional Modes: 1.6x
*Additional Crop Occurs in Select Video Modes |
| Image Stabilisation |
Sensor-Shift |
| Built-In ND Filter |
No |
| Capture Type |
Stills & Video |
| Exposure Control |
|
| Shutter Type |
Electronic Rolling Shutter |
| Shutter Speed |
1/8000 to 30 Seconds |
| Bulb/Time Mode |
No |
| ISO/Gain Sensitivity |
Native: 100 to 64,000 (50 to 102,400 Extended)
Video
*Native: 100 to 25,600
*Base ISO Is Dependant on Selected Colour Space |
| Metering Method |
Centre-Weighted Average, Evaluative, Partial, Spot |
| Exposure Modes |
Aperture Priority, Auto, Manual, Programme, Shutter Priority |
| Metering Range |
-3 to 20 EV |
| White Balance |
Presets: AWB, Auto, Manual |
| Continuous Shooting |
Up to 40 fps at Maximum Resolution |
| Interval Recording |
Yes |
| Self-Timer |
2/10-Second Delay |
| Still Image Capture |
|
| Aspect Ratio |
1:1, 3:2, 4:3, 16:9 |
| Image File Format |
C-RAW, HEIF, JPEG |
| Bit Depth |
12-Bit |
| Video Capture |
|
| Internal Recording |
Raw 12-Bit
6960 x 4640 at 23.98/24.00/25/29.97 fps
6960 x 3672 at 23.98/24.00/25/29.97/50/59.94 fps
H.264/MP4/XF-AVC S 4:2:2/4:2:0 8/10-Bit
6912 x 4608 up to 29.97 fps
4096 x 2160 at 23.98/24.00/25/29.97/50/59.94/100/120 fps
3840 x 2160 at 23.98/25/29.97/50/59.94/100/120 fps
2048 x 1080 at 23.98/24.00/29.97/50/59.94/100/120/150/180 fps
1920 x 1080 at 23.98/29.97/50/59.94/100/120/150/180 fps
H.265/MP4/XF-HEVC S 4:2:2/4:2:0 10-Bit
6912 x 4608 up to 29.97 fps
4096 x 2160 at 23.98/24.00/25/29.97/50/59.94/100/120 fps
3840 x 2160 at 23.98/25/29.97/50/59.94/100/120 fps
2048 x 1080 at 23.98/24.00/29.97/50/59.94/100/120/150/180 fps
1920 x 1080 at 23.98/29.97/50/59.94/100/120/150/180 fps |
| Video Output |
4:2:2/ProResRAW via HDMI
6960 x 3672 at 25/29.97 fps |
| Fast-/Slow-Motion Support |
Slow-Motion Only |
| Gamma Curve |
Canon Log 2, Canon Log 3, HDR-HLG, HDR-PQ, Rec709 |
| Recording Limit |
No |
| IP Streaming |
UVC/UAC
3840 x 2160 at 29.97p, 59.94p
1920 x 1080 at 29.97p, 59.94p |
| Built-In Microphone |
Stereo |
| Audio Recording |
4-Channel 24-Bit LPCM Audio
2-Channel 16-Bit AAC Audio |
| Interface |
|
| Media/Memory Card Slot |
Slot 1: CFexpress Type B
Slot 2: SD/SDHC/SDXC (UHS-II) |
| Internal Storage |
No |
| Video I/O |
1x HDMI Output |
| Audio I/O |
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
1x 1/8" / 3.5 mm TRS Stereo Microphone Input |
| Power I/O |
1x USB-C Input |
| Other I/O |
1x 2.5 mm Sub-Mini (Remote) Input
1x USB-C 3.1/3.2 Gen 2 (Data) Output (Shared with Power Input) |
| Wireless |
Wi-Fi 5 (802.11ac) / Bluetooth 5.1 |
| Mobile App Compatible |
Yes: Android & iOS
App Name: Canon Camera Connect
Functionality: Access Stored Files, Adjust Settings, Firmware Update, Remote Control, Setup |
| Global Positioning (GPS, GLONASS, etc.) |
GPS
*Via Connected Smartphone |
| Monitor |
|
| Display Type |
Articulating 3" Touchscreen LCD |
| Resolution |
1,620,000 Dot |
| Viewfinder |
|
| Type |
No Viewfinder Support |
| Focus |
|
| Focus Type |
Auto and Manual Focus |
| Focus Mode |
Continuous-Servo AF, Manual Focus, Single-Servo AF, Subject Tracking (Animals/People/Vehicles) |
| Flash |
|
| Built-In Flash/Light |
No |
| Non-Shoe Flash Connection |
No |
| General |
|
| Battery |
1x Canon LP-E6P Rechargeable Lithium-Ion, 2130 mAh (Included) |
| Shoe Mount |
1x Hot Shoe |
| Tripod Mount |
1x 1/4"-20 Female (Bottom)
1x 1/4"-20 Female (Side) |
| Materials |
Aluminium, Magnesium Alloy, Polycarbonate |
| Operating Conditions |
32 to 104°F / 0 to 40°C up to 85% Humidity |
| Dimensions (W x H x D) |
55.8 x 32.8 x 31.4" / 141.8 x 83.3 x 79.7 cm |
| Weight |
1.3 lb / 598 g (Body Only)
1.5 lb / 688 g (With Battery, Recording Media) |
