Pioneer DJ PLX-500-W High-Torque, Direct-Drive Turntable (White)

Product #74987 | SKU PLX500W | Pioneer DJ
Usually ships in 4 - 6 weeks what does this mean?
Our Price $779.00
Usually ships in 4 - 6 weeks what does this mean?
- +

Email me when stock arrives

Shipping & Availability
Usually ships in 4 - 6 weeks. Deliver to Auckland for $28.00 Change location
Click & Collect Availability
Wellington Out of stock. Pickup in 4 - 6 weeks
Click & Collect

Features

  • User-Friendly Control Layout
  • High-Torque Direct-Drive Motor System
  • Tempo Control with ±8%
  • Built with Vibration Damping
  • USB Output

Related Products


Description

The white Pioneer DJ PLX-500-W High-Torque, Direct-Drive Turntable (White) is a high-quality, direct-drive turntable with a high-torque motor system that's designed for personal listening and live performance applications such as DJing at a party or in a club. The turntable utilises a classic layout that DJs are familiar with, including tempo control, a start/stop button, and a lighted speed guide. The high-torque motor is capable of at least 1.6 kg/cm of torque and can reach a rotational speed of 33-1/3 rpm in one second or less. A tempo adjustment of ±8%, allows you to beat-match two tracks for seamless track transitions.

The turntable is built to reproduce high-quality sound and utilises the shortest possible audio routing, from the stylus to the outputs, to reduce distortion. A phono/line switch provides flexible connections to a DJ mixer, directly to a sound system, or to powered speakers without the need for a turntable preamp. Additionally, the Pioneer PLX-500 offers a USB port for high-quality digital recordings to your Mac or PC.

The universal type S-shape tone arm offers a gimbal-supported bearing structure and a static balance type. The Pioneer PLX-500 ships with a headshell (cartridge & stylus included), a slip mat, a dust cover, a balance weight, a shell weight, an adapter for EP records, a power cord, a USB Cable, and an audio adapter cable.

Key Features:

Professional Sound Design

The PLX-500 is built to produce a high-quality vinyl sound. The shortest possible audio routing from the stylus to the outputs reduces distortion, while the phone/line output switch lets you connect directly to your sound system or to powered speakers with no need for an external amplifier

Easy Digital Recording

Record your vinyl collection to high-quality digital files by simply connecting the turntable to your PC or Mac via the USB out

Smooth DJ Play

Use the PLX-500 to mix and scratch your vinyl records or combine the turntable with rekordbox dvs, a compatible DJ mixer, and the RB-VS1-K Control Vinyl to play and perform with your digital files

Cover Art Display

Put your record covers on display while listening to your vinyl thanks to the sleeve stand inside the dust cover

Start from Scratch

This turntable comes with all the accessories you need to get started: a dust cover with jacket stand, a slipmat, and a silver edition PC-HS01-S headshell (cartridge and stylus included)

rekordbox dvs

When you use the rekordbox dj software, you can also purchase the optional rekordbox dvs "Plus Pack" to get low latency scratch control with music from your rekordbox library

Specifications

Drive Method Servo type direct drive
Motor 3-phase brushless DC motor
Brake Electronic brake
Maximum Rotation Speed 33⅓, 45, 78 rpm
Adjustment Range ±8%
Wow and Flutter 0.15% or less WRMS
S/N Ratio 50 dB or higher
Turntable Aluminium Die-Casting Diameter: 13.1" / 332.0 mm
Torque Starting Torque: 3.5 lb / 1.6 kgf-cm or more
Start Time Within 1 sec (at 33⅓ rpm)
Arm Type Universal type S-shape tone arm, gimbal-supported type bearing structure, static balance type
Effective Arm Length 9.1" / 230.5 mm
Overhang 0.6" / 16.0 mm
Tracking Error Angle Within 3°
Height Adjustment 0.2" / 6.0 mm
Stylus Stylus Pressure Variable Range: 0 to 0.1 oz / 0 to 4.0 g (1 scale 0.1 g)
Cartridge Weight Single Cartridge: 0.34 oz / 9.50 g or less
Output Voltage Phono: 1.5 mV/1 kHz
Line: 150 mV/1 kHz
General
Audio Connector 2 x RCA (left and right stereo pair)
USB 1 x USB type-B
Power Requirements 110 to 120 VAC or 220 to 240 VAC, 50/60 Hz
Power Consumption 11 W
Dimensions (W x H x D) 17.7 x 6.3 x 14.5" / 450.1 x 159.0 x 368.0 mm
Weight 23.6 lb / 10.7 kg

In The Box

  • Pioneer DJ PLX-500-W High-Torque, Direct-Drive Turntable (White)
  • Slip Mat
  • Dust Cover with Jacket Stand
  • 45 Adapter
  • Headshell with Cartridge
  • Balance Weight
  • Shell Weight
  • Audio Adapter Cable (Stereo Pin Plug (F) to Stereo Mini Plug (M)
  • USB Cable
  • Power Cord
