Rean 8-Input Stage Box (Type C, Length 1)
Special Order
Usually ships in 8 - 12 weeks
Our Price
$129.00
Special Order
Usually ships in 8 - 12 weeks
Email me when stock arrives
Shipping & Availability
Usually ships in 8 - 12 weeks.
Deliver to
Auckland
for $8.90
Change location
Click & Collect Availability
Wellington
Out of stock.
Pickup in
8 - 12 weeks
Click & Collect
Features
- Modular connector box
- Easy to assemble
- 8 3-Pole XLR Inputs (Female/Send)
Description
The *Rean 8-Input Stage Box (Type C, Length 1) is used to connect microphones and other equipment to multicore cables. It is supplied as a disassembled set comprising of all hardware parts including plates, profiles, strain relief, end pieces, and screws.
Specifications
| Contact Resistance |
<5 mΩ (inner) |
| Dielectric Strength |
0.5 kVDC |
| Insulation Resistance |
>1 GΩ |
| Rated Current Per Contact |
2 A |
| Cable O.D. |
0.59 to 0.78" (15 to 20 mm) multicore |
| Insertion Force |
<10 N |
| Withdrawal Force |
>10 N |
| Lifetime |
>1,000 mating cycles |
| Wire Size |
0.22 and 0.14 mm² 24 and 26 AWG |
| Plate |
Quad: POM |
| End Pieces |
Thermoplastic |
| Temperature Range |
-13 to 158°F (-25 to 70°C) |
| Dimensions (WxHxL) |
Overall: 3.43 x 3.04 x 9.94" (87 x 77 x 252 mm) |
In The Box
- Rean 8-Input Stage Box (Type C, Length 1)
Reviews
(no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:Give it a quick rating:
Thanks for your rating!
Write a review
Details
- Product: Rean 8-Input Stage Box (Type C, Length 1)
- Manufacturer: Rean
- Model: NSB1C-8/0
- SKU: NSB1C-8/0
- RM Product #: 26277
- Cable Connector: XLR 3-pin TA3F Female
- Cable Connector: XLR 3-pin TA3M Male
