The Rean NSB1A-8/4 Type A Stage Box (8 Input / 4 Output, Length 1) is used to connect microphones and other equipment to multicore cables. It features 8 inputs (female/send) and 4 outputs (male/return). It is supplied as a disassembled set comprising of all hardware parts including plates, profiles, strain relief, end pieces, and screws.
Rean NSB1A-8/4 Type A Stage Box (8 Input / 4 Output, Length 1)
Special Order Usually ships in 3 - 4 weeks
Our Price
$1,339
Special Order Usually ships in 3 - 4 weeks
Email me when stock arrives
Shipping & Availability
Usually ships in 3 - 4 weeks.
Deliver to
Auckland
for $8.90
Change location
Click & Collect Availability
Wellington
Out of stock.
Pickup in
3 - 4 weeks
Click & Collect
Features
- Modular connector box
- Easy to assemble
- Twelve 3-pole XLR IDC receptacles
Description
Specifications
| Contact Resistance |
<5 mΩ (inner) |
| Dielectric Strength |
0.5 kVDC |
| Insulation Resistance |
≥1 GΩ |
| Rated Current Per Contact |
2 A |
| Cable O.D. |
15 to 20 mm multicore |
| Insertion Force |
≤10 N |
| Withdrawal Force |
≤10 N |
| Lifetime |
>1,000 mating cycles |
| Wire Size |
0.22 and 0.14 mm², 24 and 26 AWG |
| Quad Plates |
POM |
| End Pieces |
Thermoplastic |
| Temperature Range |
-13 to 158°F (-25 to 70°C) |
| Dimensions (WxHxL) |
Stage Box: 5.27 x 3.11 x 5.19" (134 x 79 x 132 mm) Strain Relief: 4.92" (120 mm) |
In The Box
- Rean NSB1A-8/4 Type A Stage Box (8 Input / 4 Output, Length 1)
Reviews
(no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:Give it a quick rating:
Thanks for your rating!
Write a review
Details
- Product: Rean NSB1A-8/4 Type A Stage Box (8 Input / 4 Output, Length 1)
- Manufacturer: Rean
- Model: NSB1A-8/4
- SKU: NSB1A-8/4
- RM Product #: 22716
- Cable Connector: XLR 3-Pin Female
