Sachtler 2570 SYSTEM 25 PLUS CIII Pedestal System
Product #40650 | SKU ST-2570-NZ
Usually ships in 3 - 4 weeks
0.0 (no ratings yet) Thanks for your rating!


Sachtler 2570 SYSTEM 25 PLUS CIII Pedestal System

Product #40650 | SKU ST-2570-NZ
Usually ships in 3 - 4 weeks


Product Features
  • CIII Pedestal
  • System 25 Plus Head
  • Multi Disc
  • 35 kg Capacity
Customer Reviews
0.0 (no ratings yet) Thanks for your rating!
Email me when stock arrives
Product Details
  • Product: #40650
  • SKU: ST-2570-NZ
Our Price $36,299.00

Delivery - $32.00*
3 - 4 weeks
Pickup AUCKLAND
3 - 4 weeks
Pickup WELLINGTON
3 - 4 weeks
*estimated shipping to Auckland

Overview

The Sachtler 2570 System 25 Plus CIII Pedestal is designed with today's camera person using HTDV and Widescreen cameras in mind. The System 25 Plus Pedestal system consists of the, Video 25 Plus fluid head with its seven step, temperature-independent damping system. This head is matched with the CIII compact pedestal and Multi Disc for a complete package.

Key Features

Video 25 Plus Fluid Head

Frictionless Leak Proof Fluid Damping
Frictionless leak proof fluid damping with seven levels of drag, for perfect pictures while panning, without jerks and vibrations. Identical across both horizontal and vertical planes, and allows complete disengagement of drag for fast panning.

Quick Release
Touch & Go Quick Release / Automatic Locking System, for quick set up without having to bother screwing the camera to head and then having to unscrew it again. Also features a safety lock lever that prevents inadvertent disengagement of the camera latch.

Sliding Balance Plate
Sliding camera mount and plate with a 4.4-inch(11.1 cm) sliding range, makes a fast balancing system for the camera and ensures perfect balance across the horizontal plane.

Dynamic Counterbalancing System
The 18 Step dynamic counterbalancing system, with 9-stage fine-tuning in half steps compensates for torques as the camera tilts. This prevents the camera from inadvertently tipping, and ensures that it is positioned securely at any tilt angle. These features can be activated and deactivated individually.

CIII Pedestal System

Air Pressurised Pneumatic Column The pedestal is anchored by a pneumatic column. The system works on the principle of compressed air, which acts as a counterweight and allows for quick height adjustments. An air pressure gauge gives the user instant indication of correct pressure.

Silent Dolly Movement
Silent dolly movement is very important in a studio where sounds can easily carry into the production.

Set-Up
This pedestal offers a fast tool-free set-up for productions on the go.

Specifications

General
Load Capacity 8-35 kg
Trim Ring No
Bowl Diameter/Thread Sachtler/Vinten Flat Base Fitting
100mm Bowl
Steering Ring Diameter 12"
(300mm)
Minimum Height 35.8" (91 cm)
Maximum Height 69.3" (176 cm)
Levelling Bubble/Illuminated Yes / Illuminated
Weight 22.6 kg
Head
Balance Plate Yes, 4.4" Sliding Range
Tilt Drag Yes
Tilt Range +90° to -75°
Tilt Lock Yes
Spring Loaded Counter Balance 8 steps, 0 to 7
Pan Range 360°
Pan Lock Yes
Dolly
Doorway Width 39"
(99cm)
Wheel Diameter 6"
(154mm)
Wheel Lock Yes
Cable Guards Yes
Weight 16.5kg

In The Box

Sachtler 2570 SYSTEM 25 PLUS CIII Pedestal System
  • Video 25 Plus Fluid Head
  • CIII Pedestal
  • Multi Disc
  • Limited 1-Year Warranty, Extendable to 2-Years with Product Registration

Reviews

0.0 (no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:
Write a review
Details
  • Product: Sachtler 2570 SYSTEM 25 PLUS CIII Pedestal System
  • Manufacturer: Sachtler
  • Model: ST-2570-NZ
  • SKU: ST-2570-NZ
  • RM Product #: 40650
  • Head Type: Fluid
  • Load Capacity: 35.0 kg
  • Weight: 22.60 kg
  • Maximum Height: 176.0 cm
  • Minimum Height: 91.0 cm
