Use the Sachtler PTZ HD Pedestal System for simple positioning & repositioning of a PTZ Camera with optional teleprompter in a space where the PTZ can be simply moved around the floor. Additionally, small height adjustments for eyeline can be made without de-rigging.
Specifications
Sachtler 4191 Pedestal C I System (Flat Base) With Dolly 75
General
Load Capacity
44.1 lb (20 kg)
Trim Ring
No
Bowl Diameter/Thread
100 mm
Steering Ring Diameter
5.6" (142.2 mm)
Folded/Transport Length
Not Specified By Manufacturer
Minimum Height
26.8" (68 cm)
Maximum Height
61.8" (157 cm)
Weight
20.3 lb (9.2 kg)
Post
Stages
1
On-Shot Stroke
15.4" (39 cm)
Dolly
Doorway Tracking Width
32" (81 cm)
Transit Doorway Width
No
Narrow Doorway Width
Not Applicable
Wheel Diameter
4" (10.1 cm)
OConnor 08349 Sachtler/Vinten Base Specs
Use
To attach to any flat base Sachtler or Vinten tripod or pedestal (4 bolt / 3 bolt / quickfix)
Tiedown
Not required
V4166-1002 PTZ or Prompter Plate
Use to Mount
1. Any PTZ camera where the tapped mounting holes on the underside are in line with the lens centre of the camera.2. To fit to the bottom of a prompter bracket when the PTZ is mounted to a prompter.
