Sachtler VIDEO 90 FB Fluid Head (Flat Base)
Product #40736 | SKU ST-8092-NZ
Usually ships in 3 - 4 weeks
0.0 (no ratings yet) Thanks for your rating!


Sachtler VIDEO 90 FB Fluid Head (Flat Base)

Product #40736 | SKU ST-8092-NZ
Usually ships in 3 - 4 weeks


Product Features
  • Frictionless Leak Proof Fluid Damping
  • Sliding Balance Plate
  • 24 Step Dynamic Counterbalancing System
  • Vibration-Free Vertical and Horizontal Brakes
  • QuickFix Mount
Customer Reviews
0.0 (no ratings yet) Thanks for your rating!
Email me when stock arrives
Product Details
  • Product: #40736
  • SKU: ST-8092-NZ
Our Price $26,599.00

Delivery - $16.00*
3 - 4 weeks
Pickup AUCKLAND
3 - 4 weeks
Pickup WELLINGTON
3 - 4 weeks
*estimated shipping to Auckland

Overview

Professional camera operators choose the Video 90 for OB and studio applications for good reasons. Lightweight, but able to support loads up to 115 kg, due to it's ergonomic, robust, squeeze-proof design, which ensures safe operation in any position.

Also features a high-performance, jerk-free damping system with Seven Levels of Drag allowing the use of long focal lengths in OB applications, Vibration-Free Vertical and Horizontal Brakes, guaranteeing exceptionally smooth operation. And if you need to change equipment frequently, the Video 90 FB comes with the QuickFix mount allowing you to mount quickly, to save time.

Key Features

  • Using teleprompters and you need to add counterweights, no problem, the Video 90 FB supports maximum loads up to 90 kg.

  • Built-in bubble for horizontal levelling

Frictionless leak proof fluid damping with Seven Levels of Drag
A prerequisite for perfect pictures is a panning movement without jerks and vibrations. Sachtler's patented damping system takes everything is stride. The individual modules are frictionless and contain no hydraulic oil. This means they are permanently leak proof. The damping action of heads is identical across both horizontal and vertical planes and offers you seven steps of drag, for smooth camerawork under the toughest of rough conditions. You can completely disengage the drag for fast panning without affecting the dynamic counterbalance system.

Sliding Balance Plate
The sliding camera mount and plate with a 7.1-inch(18.0 cm) sliding range, allows you to compensates precisely for a variety of configuration weights. Ensuring perfect balance across the horizontal plane. Most importantly, once adjusted, the settings cannot be lost. Also features two built-in threaded holes for the teleprompter tubes, a standard feature of the Video 90 FB sliding plate, allows you to place the teleprompter right next to the rotating axis.

24 Step dynamic counterbalancing system plus fine tuning
Built with torsion springs the dynamic counterbalancing system compensates for torques as the camera tilts, preventing the camera from inadvertently tipping, and ensuring that it is positioned securely at any tilt angle. Freeing you to concentrate fully on your camerawork. Its 24-step counterbalance with fine tuning adjustments allows a variety of equipment to be used, and can be activated and deactivated individually. Independent from the damping system, they work silently and without the need for maintenance.

Vibration-Free Vertical and Horizontal Brakes
The Video 90 FB features direct-response horizontal and vertical brakes. Mounted on the back of the head, they are absolutely vibration-free, thus guaranteeing exceptionally smooth operation.

QuickFix Mount
The Sachtler Quickfix lets you mount flat base heads with a single screw. This saves a lot of time, especially if you have to change equipment frequently and quickly, which is all in a normal day's work in OB environments.

Safe at any temperature
Pressure or temperature does not influence the damping system, it has an operating range from -40°C to +60°C, and works without friction. Shoot wherever you want, from torrid heat to cold climates.

Specifications

Load Capacity 0-115 kg
Diameter/Thread Flatbase
Counter Balance System Torsion Springs
Counter Balance Range 24 Steps
Quick Release/Wedge Plate Yes
Balance Plate Yes, 7.1"(18.0 cm) Sliding Range
Tilt Drag 8 steps, 0 to 7
Tilt Range +60° to -45°
Tilt Lock Yes
Pan Drag 8 steps, 0 to 7
Pan Range 360°
Pan Lock Yes
Levelling Bubble/Illuminated Yes / No
Temperature Range -40° to 60°C
Weight 14.4 kg

In The Box

  • Sachtler VIDEO 90 FB Fluid Head (Flat Base)
  • Right Front Section Pan Bar
  • Left Front Section Pan Bar
  • Quick Release / Wedge Plate
  • Limited 1-Year Warranty, Extendable to 2-Year with Product Registration
