| System |
|
| Wireless Technology |
Digital 2.4 GHz/5.8 GHz |
| Included Transmitters |
1 x Bodypack |
| Diversity |
True Digital Diversity |
| RF Channel Scanning |
Auto-Scan |
| Max Operating Range |
30.5 m (Line of Sight) |
| Max Transmitters per Band |
8 |
| Mobile App Compatible |
No
*As of February, 2023: Cheque with manufacturer for the most up-to-date compatibility |
| Dynamic Range |
120 dBA |
| Modulation |
Proprietary |
| Receiver |
|
| Receiver Type |
Rackmount |
| Mounting Options |
Rackmount (with Included Hardware) |
| Rackmount Size |
1 RU (1/2 Rack) |
| Antenna |
2 x 1/2 Wave Sleeve Dipole, Detachable (Rear-Mount) |
| Number of Audio Channels |
1 |
| Audio I/O |
1 x XLR 3-Pin Male Balanced Output
1 x 1/4" TRS Female Balanced Output |
| Gain Range |
-18 to +42 dB (1 dB Steps) |
| Pad |
30 dB |
| Audio Output Level |
XLR Output:
+18 dBV (Line Level)
XLR Output:
-12 dBV (Mic Level)
1/4" Output:
+12 dBV |
| Frequency Response |
20 Hz to 20 kHz (Dependant on Mic) |
| USB/Lightning Connectivity |
1 x USB-C Female (Firmware Update) |
| Impedance |
XLR Output:
100 Ohms (Balanced)
1/4" Output:
100 Ohms (Balanced)
50 Ohms (Unbalanced) |
| Approximate RF Sensitivity |
-88 dBm |
| Spurious |
Rejection: >35 dB |
| Power Requirements |
AC/DC Power Adapter |
| AC/DC Power Adapter |
14.5 to 17 VDC at 600 mA (Included) |
| AC Input Power |
100 to 240 VAC, 50 / 60 Hz |
| Display & Indicators |
1 x Backlit LCD (AF Level, Channel, Frequency, Group, Transmitter Battery Status) |
| Housing |
Steel |
| Operating Temperature |
0 to 45°C |
| Dimensions |
197 x 42 x 163 mm (without Antennas) |
| Weight |
30.5 oz / 866 g |
| Transmitter |
|
| Transmitter Type |
Bodypack |
| RF Output Power |
10 mW (EIRP) |
| Audio I/O |
1 x TA4/Mini XLR 4-Pin Male Unbalanced Input (Lockable) |
| Pad |
None |
| Muting |
Off/On Switch |
| Audio Input Level |
-8.4 dBV / 7.5 V p-p |
| Gain Range |
-18 to +42 dB (1 dB Steps) |
| Sync Method |
Proprietary |
| Antenna |
1 x Internal, Fixed (Beltpack) |
| Power Requirements |
Battery |
| Battery Type |
1 x Shure SB904 (Included, Replaceable) |
| Internal Battery Capacity |
2420 mAh |
| Battery Charging Time |
.25 to 3 Hours |
| Approx. Battery Life |
12 Hours (Lithium Rechargeable) |
| USB/Lightning I/O |
1 x USB-C (Charging) |
| Display & Indicators |
1 x LED (Battery Status, Sync) |
| Housing |
Metal |
| Dimensions |
2.6 x 4.5 x 1.1" / 67 x 115 x 28.5 mm |
| Weight |
5.4 oz / 153.1 g (without Batteries) |
