| Sirui IronStar 35mm T1.9 Anamorphic 1.5x Lens (ARRI PL/Canon EF, Blue) |
|
| Focal Length |
35mm |
| Maximum Aperture |
T1.9 |
| Minimum Aperture |
T16 |
| Lens Mount |
Interchangeable Mount with Included ARRI PL/Canon EF |
| Horizontal Squeeze (Anamorphic) |
1.5x |
| Flare Colour |
Blue |
| Lens Format Coverage |
Full-Frame (46 mm Image Circle) |
| Angle of View |
Vertical: 39.64°
Horizontal: 79.98°
Diagonal: 83.88° |
| Focus Scales |
Metric, Imperial |
| Optical Design |
20 Elements in 16 Groups |
| Filter Thread |
92 mm x 0.75 |
| Minimum Focus Distance |
From Camera Sensor: 25.6" / 65 cm |
| Magnification |
1:23.26 Macro Reproduction Ratio
0.04x Magnification |
| Aperture/Iris Blades |
16 |
| Image Stabilisation |
No |
| Lens Mounting |
2x 1/4"-20 (via Included Support Foot) |
| Gear Standard |
Focus, Iris: 0.8 MOD |
| Gear Rotation |
Focus: 270° |
| Electronic Communication |
Yes |
| Diameter |
Front: 3.7" / 95 mm |
| Length |
5.2" / 131 mm (Canon EF)
4.8" / 123 mm (ARRI PL) |
| Weight |
2.2 lb / 998 g
2.3 lb / 1 kg |
| Sirui IronStar 45mm T1.9 Anamorphic 1.5x Lens (ARRI PL/Canon EF, Blue) |
|
| Focal Length |
45mm |
| Maximum Aperture |
T1.9 |
| Minimum Aperture |
T16 |
| Lens Mount |
Interchangeable Mount with Included ARRI PL/Canon EF |
| Horizontal Squeeze (Anamorphic) |
1.5x |
| Flare Colour |
Blue |
| Lens Format Coverage |
Full-Frame (46 mm Image Circle) |
| Angle of View |
Full Frame
Vertical: 32.08°
Horizontal: 67.55°
Diagonal: 71.1° |
| Focus Scales |
Metric, Imperial |
| Optical Design |
19 Elements in 14 Groups |
| Filter Thread |
92 mm x 0.75 |
| Minimum Focus Distance |
From Camera Sensor: 25.6" / 65 cm |
| Magnification |
1:19.23 Macro Reproduction Ratio
0.05 to 1x Magnification |
| Aperture/Iris Blades |
16 |
| Image Stabilisation |
No |
| Gear Standard |
Focus, Iris: 0.8 MOD |
| Gear Rotation |
Focus: 270° |
| Electronic Communication |
Yes |
| Diameter |
Front: 3.7" / 95 mm |
| Length |
5.4" / 137.5 mm (Canon EF)
5.1" / 129.5 mm (ARRI PL) |
| Weight |
2.2 lb / 990 g
2.25 lb / 1.02 kg |
| Sirui IronStar Series 60mm T1.9 Anamorphic 1.5x Lens (Blue Flare) |
|
| Focal Length |
60mm |
| Maximum Aperture |
T1.9 |
| Minimum Aperture |
T16 |
| Lens Mount |
Interchangeable Mount with Included ARRI PL/Canon EF |
| Horizontal Squeeze (Anamorphic) |
1.5x |
| Flare Colour |
Blue |
| Lens Format Coverage |
Full-Frame (46 mm Image Circle) |
| Angle of View |
Vertical: 23.59°
Horizontal: 50.63°
Diagonal: 53.82° |
| Focus Scales |
No |
| Optical Design |
19 Elements in 14 Groups |
| Filter Thread |
92 mm |
| Minimum Focus Distance |
2.56' / 0.78 m |
| Magnification |
1:17.86 Macro Reproduction Ratio
0.05x Magnification |
| Aperture/Iris Blades |
16 |
| Image Stabilisation |
No |
| Gear Rotation |
Focus: 270° (Manual Only) |
| Electronic Communication |
No |
| Diameter |
3.7" / 95 mm |
| Length |
5.6" / 142 mm (EF Mount)
5.3" / 134 mm (PL Mount) |
| Weight |
2.3 lb / 1023 g
2.3 lb / 1044 g |
