Sonnet Echo 20 SecureDock 9-Port Multi-Adapter Hub with HDMI and DisplayPort

Product #125724 | SKU ECHO-DK20-T5 | Sonnet
Contact us for an ETA what does this mean?
Contact us for an ETA what does this mean?
This product can't be purchased at this time, please contact us for more information.
- +

Email me when stock arrives


Features

  • 1 x Thunderbolt 5 Port
  • Up to 140W of Pass Through Charging
  • 1 x HDMI & 1 x DisplayPort
  • 2 x Thunderbolt 5 Ports
  • 5 x USB-C Ports up to 10 Gb/s
  • 4 x USB-A Ports up to 10 Gb/s

Description

Designed with enterprise environments as a priority, the Sonnet Echo 20 SecureDock 9-Port Multi-Adapter Hub with HDMI and DisplayPort is tailored for organizations that restrict built-in storage, ensuring compliance while delivering advanced connectivity options for your laptop.

High-Speed Thunderbolt 5 Connection

A single Thunderbolt 5 host connection provides powerful features, including 140W charging capacity, up to 80 Gb/s bi-directional data bandwidth, and as much as 120 Gb/s of display bandwidth.

Advanced Display Support

Expand your desktop by supporting a single 8K60 or 4K144 display, or connect up to four monitors at resolutions up to 6K, using a mix of HDMI, DisplayPort, and two Thunderbolt 5 ports.

Extensive Connectivity Options

The hub includes nine USB ports, both microSD and SD card slots, 10 Gb/s Ethernet for fast network access, as well as multiple audio interfaces to cover a wide range of professional needs.

Specifications

USB I/O 2x USB-C (Thunderbolt 5) / Supports Video Alt Mode
1x USB-C 3.1/3.2 Gen 2 / Supports 15 W Output
4x USB-C 3.1/3.2 Gen 2 / Supports 7.5 W Output
4x USB-A 3.0 / 3.1/3.2 Gen 1 / Supports 7.5 W Output
Video I/O 1x HDMI 2.1 (Female)
1x DisplayPort 2.0 (Female)
Max Resolution 4 Displays Supported:
7680 x 4320 at 60 Hz (Single)
6016 x 3384 (Quad)
Audio I/O 1x 1/8" / 3.5 mm Headphone/Microphone Combo Jack
1x 1/8" / 3.5 mm Microphone Input
1x 2RCA (L/R Audio)
Network I/O 1x RJ45 (10 GbE)
Media Card Reader 1x microSDXC
1x SDXC
Host Connection USB-C (Thunderbolt 5) Supporting USB Power Delivery up to 140 W via Detachable Cable
Power Source Included AC Adapter with USB-C Connector
Wireless Charging No
OS Compatibility Computer: macOS / Windows / Chrome OS
Mobile: iPadOS Only
Operating Conditions 32 to 95°F / 0 to 35°C
Lock Slot Yes: Kensington
Certifications CISPR 32/EN 55032, FCC Part 15, Subpart B, IEC62368-1, IEC62368-2, PSE, RoHS 3 (Directive 2015/863), UL, VCCI-B
Cable Length 2.6' / 0.8 m
Dimensions 9.6 x 4.2 x 1.3" / 24.3 x 10.6 x 3.3 cm
Weight 4.2 lb / 1.9 kg

In The Box

  • Sonnet Echo 20 SecureDock 9-Port Multi-Adapter Hub with HDMI and DisplayPort
  • Thunderbolt 5 Cable (2.6')
  • ThunderLok-A Connector Lock
  • Power Adapter
  • Power Cord
