StarTech 3-Port HDBaseT Extender Kit with 3 Receivers

Product #83206 | SKU ST124HDBT | Startech
Contact us for an ETA what does this mean?
Our Price $2,999.00
Contact us for an ETA what does this mean?
This product can't be purchased at this time, please contact us for more information.
- +

Email me when stock arrives


Features

  • Extends your HDMI video signal
  • A complete extender kit
  • Maintains UHD 4K up to 115 feet away
  • Mountable, to install securely and out of the way
  • Dolby® TrueHD, DTS-HD MA Audio

Related Products


Description

This StarTech 3-Port HDBaseT Extender Kit with 3 Receivers lets you extend an HDMI® source to three remote locations, using HDBaseT technology. The kit includes three remote receiver units, and the transmitter features a local HDMI output, which gives you the ability to keep a fourth HDMI display at your local video source.

Key Features:

A complete extender kit that includes transmitter and receivers

This all-in-one extender kit saves you the complications and compatibility issues that can happen if you're not using the correct receivers. It’s perfect for use in corporate environments such as small or large offices, or in retail, hospitality, and educational establishments.

Astonishing 4K picture quality from an impressive distance

With the A/V industry adopting 4K as its new high-resolution standard, long-range video distribution can be difficult, especially considering the 4K distance limitations on standard HDMI cables. You’ll be amazed at how this HDBase-T extender kit can deliver your video signal to three different locations while maintaining 4K Ultra HD picture quality. You get four times the resolution of high-definition 1080p, even at 115 feet (35 m) away from your video source.

The extender is also backward compatible with 1080p at 230 feet (70 m), so you can comfortably use it to make any video source look great.

Professional installation

HDBaseT technology offers a single-cable installation, so you can integrate this solution seamlessly using your existing CAT5e or CAT6 infrastructure. Plus, each device included with the HDBaseT extender kit is mountable, so you can keep the equipment out of sight in an equipment rack, or on a wall. This helps to reduce clutter and ensure a professional installation that doesn't draw your viewers' attention away from the content on your display. It’s perfect for customer-facing displays in bars or restaurants.

What is HDBaseT?#####

HDBaseT is a standardized, zero-latency video technology that’s revolutionizing HDMI distribution. HDBaseT uses an advanced method of modulation that enables you to distribute uncompressed HDMI audio and video, along with additional signals, over a single Ethernet cable.

Offering greater versatility than traditional HDMI extenders, and longer distances than HDMI cables alone, HDBaseT is the clear choice for every integrator and system designer. It can do so much, with just a single cable.

Specifications

Environmental
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -10°C to 60°C (14°F to 140°F)
Humidity 0% - 80 % RH (non-condensing)
Hardware
Ports 4
Cabling Cat 5e UTP or better
Audio Yes
Rack-Mountable Yes
Daisy-Chain Yes
Packaging Information
Package Height 3.9 in [98 mm]
Package Length 14.3 in [36.3 cm]
Shipping (Package) Weight 5.8 lb [2.6 kg]
Package Width 11.8 in [29.9 cm]
Performance
Maximum Cable Length 229.6 ft [70 m]
Max Distance 70 m / 230 ft
Maximum Digital Resolutions 4096 x 2160 (4K) @ 30 Hz - maximum distance 35 m (115 ft.)
1920x1080 (1080p) - maximum distance 70 m (230 ft.)
Supported Resolutions 4k x 2K (Ultra HD) @ 30 Hz
2560x1600 @ 60 Hz
1920x1200
1920x1080 (1080p)
1280x720 (720p)
General Specifications Maximum 1080p Distance: 70 m (230 ft.)
Maximum 4K Distance: 35 m (115 ft.)
Physical Characteristics
Material Steel
Product Length 7.9 in [20 cm]
Product Width 5.7 in [14.5 cm]
Product Height 1.2 in [30 mm]
Weight of Product 35.3 oz [1000 g]
Power
Power Source AC Adapter Included
Input Voltage 100 - 240 AC
Input Current 1.5A
Output Voltage 24 DC
Output Current 2.7A
Center Tip Polarity Positive
Plug Type 4-pin DIN
Power Consumption (In Watts) 64.8

In The Box

  • 3-port HDBaseT extender
  • 3 x HDBaseT receivers
  • universal power adapter (NA / EU / UK / AU)
  • 4 x IR blasters
  • IR receivers
  • quick start guide
