StarTech 4K HDMI Extender with Compact Transmitter (HDBaseT - UHD 4K)
this item may be nonreturnable
Features
- Simple and versatile installation
- Astonishing picture quality
- Existing CAT5/CAT6/CAT7 infrastructure
- Mounting hardware included
- 1 audio support
Related Products
Description
This StarTech 4K HDMI Extender with Compact Transmitter (HDBaseT - UHD 4K) uses HDBaseT to transmit your HDMI A/V signal to a remote location up to 70 m (230 ft.) away.
Key Features:
Easy and Discreet Installation
The transmitter in this HDMI HDBaseT extender kit features a small footprint and built-in HDMI cable that connects directly to your source for reduced clutter. It’s powered from a USB port on your source device, which makes it easier to install in areas where power outlets may be limited. Mounting hardware is included for the receiver for a discreet, professional installation.
Get 4K Video at 130 ft. (40 m)#####
This HDMI over CAT6 extender maintains your UHD 4K picture quality, even at 130 feet away from your video source. Because the extender is backward compatible with 1080p and lower resolutions at 230 feet away, you can comfortably use this extender to make any video source look great. The extender also supports 7.1 audio to ensure all audio channels are captured.
Seamless Integration with Your Existing Infrastructure
The kit extends HDMI over a single cable, unlike some HDMI extenders that require two cables, reducing potential failure points and lowering your cabling costs. Ideal for digital signage, the HDMI over CAT6 extender uses standard CAT5e, CAT6 or CAT7 cables to extend HDMI video over the Ethernet infrastructure that's already in your building.
Specifications
AV Input | HDMI |
AV Output | HDMI |
1 - Connector A | HDMI (19 pin) |
1 - Connector B | HDMI (19 pin) |
1 - Connector A | RJ-45 |
1 - Connector B | RJ-45 |
Connector(s) | |
1 - Local Unit Connectors | HDMI (19 pin) |
1 - Remote Unit Connectors | HDMI (19 pin) |
1 - Local Unit Connectors | RJ-45 |
1 - Remote Unit Connectors | RJ-45 |
Environmental | |
Operating Temperature | 0°C to 40°C (32°F to 104°F) |
Storage Temperature | -10°C to 60°C (14°F to 140°F) |
Humidity | 0% - 80 % RH (non-condensing) |
Hardware | |
Ports | 1 |
Cabling | Cat 5e UTP or better |
Audio | Yes |
Rack-Mountable | Yes |
Daisy-Chain | No |
Indicators | |
1 - LED Indicators | Status LED (receiver) |
Packaging Information | |
Package Height | 2.9 in [74 mm] |
Package Length | 11.5 in [29.3 cm] |
Shipping (Package) Weight | 3.5 lb [1.6 kg] |
Package Width | 7.7 in [19.6 cm] |
Performance | |
Max Distance | 70 m / 230 ft |
Maximum Digital Resolutions | 4096 x 2160 (4K) @ 30 Hz |
Wide Screen Supported | Yes |
Audio Specifications | 7.1 Surround Sound |
Physical Characteristics | |
Material | Steel |
Product Length | 3.1 in [80 mm] |
Product Width | 2.7 in [68 mm] |
Product Height | 1.0 in [25 mm] |
Weight of Product | 8.9 oz [252 g] |
Power | |
Power Source | AC Adapter Included |
Input Voltage | 100 - 240 AC |
Input Current | 0.6 A |
Output Voltage | 12V DC |
Output Current | 1.5 A |
Center Tip Polarity | Positive |
Plug Type | M |
Power Consumption (In Watts) | 18 |
In The Box
- HDBaseT transmitter
- HDBaseT receiver
- USB power cable (transmitter) (1310 mm)
- universal power adapter (receiver) (NA, EU, UK, ANZ)
- mounting kit (receiver)
- screw kit for mounting
- footpad set (receiver)
- quick start guide
Reviews
(no ratings yet)Give it a quick rating:
Thanks for your rating!
Write a review
Details
- Product: StarTech 4K HDMI Extender with Compact Transmitter (HDBaseT - UHD 4K)
- Manufacturer: Startech
- Model: ST121HDBTDK
- SKU: ST121HDBTDK
- RM Product #: 83103
