StarTech USB to RS232 DB9 Serial Adapter Cable (91.4cm)
Features
- Supports serial data transfer rates of up to 1 Mbps
- No external power needed
- Compatible with nearly any serial RS232 equipment
- Thin, lightweight design
- Easy to setup and install
Related Products
Description
The StarTech USB to RS232 DB9 Serial Adapter Cable (91.4cm) lets you connect DB9 RS232 serial devices to your Mac® or PC laptop or desktop computer through an available USB port, as though the computer offered an onboard DB9M connector.
Unlike typical USB to serial converter cables where the conversion takes place at the DB9 end, the StarTech.com ICUSB232SM3 features a converter chip on the USB end. Converting at the USB source overcomes the 15ft. technical limit of USB cables, allowing for a much greater serial DB-9 extension cable (50ft.+ is possible depending on the application) if necessary.
Simple to install and use, this USB to Serial adapter is a cost-effective solution that bridges the compatibility gap between modern computers and legacy serial peripherals.
Specifications
Connector | |
1 - Connector A | USB Type-A (4 pin) USB 2.0 |
1 - Connector B | DB-9 (9 pin, D-Sub) |
Environmental | |
Operating Temperature | 0°C to 60°C (32°F to 140°F) |
Storage Temperature | -20°C to 80°C (-4°F to 176°F) |
Humidity | 0~65% RH |
Hardware | |
Ports | 1 |
Interface | Serial |
Bus Type | USB 2.0 |
Port Style | Cable Adapters |
Industry Standards | RS232, USB 1.1/2.0 |
Chipset ID | Prolific - PL2303HXD |
Packaging Information | |
Package Height | 0.6 in [15.0 mm] |
Package Length | 8.7 in [22.0 cm] |
Shipping (Package) Weight | 2.5 oz [70.0 g] |
Package Width | 7.9 in [20.0 cm] |
Performance | |
Serial Protocol | RS-232 |
Max Baud Rate | 921.6 Kbps |
FIFO | 192 Bytes |
In The Box
- USB to Serial Converter
- 2 x Cable Nuts
Reviews
(no ratings yet)Give it a quick rating:
Thanks for your rating!
Write a review
Details
- Product: StarTech USB to RS232 DB9 Serial Adapter Cable (91.4cm)
- Manufacturer: Startech
- Model: ICUSB232SM3
- SKU: ICUSB232SM3
- RM Product #: 81453
- Length Meters: 91.4 m
- Cable Connector: USB Type-A Male
- Connector count: 2
- Cable Connector: DB9 D-Sub 9-pin Male
