TP-Link EAP783 BE22000 Tri-Band Wi-Fi 7 Access Point

Product #112314 | SKU TL-EAP783 | TP-Link
In Stock with Supplier Usually ships in 2 - 3 working days what does this mean?
Our Price $1,359
In Stock with Supplier Usually ships in 2 - 3 working days what does this mean?
- +

Email me when stock arrives

Shipping & Availability
Usually ships in 2 - 3 working days. Deliver to Auckland for $14 Change location
Click & Collect Availability
Wellington Out of stock. Pickup in 3 - 4 working days
Click & Collect

Features

  • Wi-Fi 7 (802.11be)
  • Up to 21,536 Mb/s Throughput
  • 2.4 GHz / 5 GHz / 6 GHz (Tri-Band)
  • 2 x 10G Ethernet PoE++ Ports
  • Thin, Compact Design
  • Ceiling & Wall Mountable

Description

The TP-Link EAP783 BE22000 Tri-Band Wi-Fi 7 Access Point offers a sleek design that seamlessly blends into various environments. This access point provides fast and dependable coverage, with a maximum throughput of 21,536 Mb/s across three frequency bands. It can support over 760 concurrent clients, ensuring coverage up to 2150 square feet.

In addition to its high bandwidth capabilities, the Wi-Fi 7 technology grants efficient and reliable connectivity with compatible devices. By connecting the two 10G Ethernet ports to a PoE++ compatible device, you can transfer both power and data effortlessly. Alternatively, you can choose to use a separate power adapter, if desired. Furthermore, this access point ensures security with enterprise-class protection, with the added convenience of managing your wireless network from virtually anywhere through the Omada cloud platform.

Specifications

Key Specs
Wi-Fi Wi-Fi 7 (802.11be); Tri-Band (2.4, 5, & 6 GHz) with MU-MIMO Support (4 x 4)
Throughput 21,536 Mb/s Total
6 GHz: 11520 Mb/s
5 GHz: 8640 Mb/s
2.4 GHz: 1376 Mb/s
Inputs/Outputs 2x RJ45 10 GbE
Wireless
Wi-Fi Wi-Fi 7 (802.11be); Tri-Band (2.4, 5, & 6 GHz) with MU-MIMO Support (4 x 4)
Antenna Gain 4 to 5 dBi
Transmit Power 24 to 28 dBm
Antenna Placement Internal
Bluetooth No
Throughput 21,536 Mb/s Total
6 GHz: 11520 Mb/s
5 GHz: 8640 Mb/s
2.4 GHz: 1376 Mb/s
Interface
Inputs/Outputs 2x RJ45 10 GbE
USB Sharing Support No
Security
Guest Network Support Yes
Wireless Security WPA, WPA-Enterprise, WPA2, WPA2-Enterprise, WPA3, WPA3-Enterprise
Lock Slot No
Management
Operation Modes Access Point
Supported Clients 380
Max SSIDs Supported 24
Mobile App Compatible Yes: Android & iOS
App Name: Omada
Hardware
Supported IEEE Standards 802.11a, 802.11ac, 802.11ax, 802.11b, 802.11be, 802.11g, 802.11n, 802.3af (PoE 15.4 W), 802.3at (PoE+ 30 W), 802.3bt Type 3 (PoE++ 60 W)
Electrical
DC Input Power 12 VDC
Power Consumption 39 W
Environmental
Operating Temperature 32 to 104°F / 0 to 40°C
Storage Temperature -40 to 158°F / -40 to 70°C
Operating Humidity 10 to 90%
Storage Humidity 5 to 90%
General
Environmental Protection No
Certifications COE, RoHS, FCC, IC
Mount Options Wall, Ceiling
Dimensions 11 x 11 x 1.8" / 280 x 280 x 46.5 mm
Weight 3 lb / 1384.6 g

In The Box

  • TP-Link EAP783 BE22000 Tri-Band Wi-Fi 7 Access Point
  • Ceiling Mounting Kit

Reviews

0.0 (no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:
Write a review

Details

  • Product: TP-Link EAP783 BE22000 Tri-Band Wi-Fi 7 Access Point
  • Manufacturer: TP-Link
  • Model: TL-EAP783
  • SKU: TL-EAP783
  • RM Product #: 112314
