Wooden Camera B-Box for RED KOMODO

Description

B-Box (RED® KOMODO ™) attaches to the camera-right BP-9 battery slot and provides a breakout for the camera’s EXT connector. Battery Slide Pro V-Mount or Gold Mount for RED KOMODO can be used simultaneously and custom right-angle LEMO compatible connector allows for neat cable run. Canon BP-9 batteries could also be attached in camera-left slot while B-Box is used.

Available ports include:

• R/S (3pin Fischer)

• simple run/stop for Handgrip Trigger Box , Simple 3pin Fischer Trigger Cable , etc.
• no power available
• devices like ARRI WCU-4 may require CTRL port interface with cable K2.0015758
• pin1:GND, pin2:N/C, pin3:GPI

• Timecode (5pin LEMO)

• standard wiring for timecode in/out
• pin1:GND, pin2:LTC-IN, pin3:N/C, pin4:N/C, pin5:LTC-OUT

• CTRL (4pin LEMO)

• standard wiring for RED CTRL
• pin1:GND, pin2:UART-RX, pin3:GPO, pin4:UART-TX

• 5V (USB)

• 5V available at 500mA maximum
• power may need to be enabled in camera menu

• Genlock (BNC)

• standard wiring for genlock
• center:signal, shell:GND
