| Key Specs |
|
| Channel Configuration |
13-Channel |
| Low-Frequency Drivers |
4x 1.8 x 3.5" / 45 x 90 mm Front-Firing Cone |
| Midrange Drivers |
2x 1.8 x 2.1" / 46 x 54 mm Up-Firing Cone |
| High-Frequency Drivers |
4x 0.4" / 10 mm Front-Firing Dome
1x 0.9" / 22 mm Front-Firing Dome |
| Full-Range Drivers |
2x 1.8 x 2.1" / 46 x 54 mm Side-Firing Cone |
| Inputs |
1x HDMI 2.1 - ARC/Audio/Video/eARC |
| Outputs |
1x HDMI 2.1 - ARC/eARC/Audio/Video
1x 1/8" / 3.5 mm - Audio |
| Wireless Audio Protocols |
AirPlay 2, Bluetooth, Spotify Connect, Wi-Fi |
| Wireless |
Wi-Fi 5 (802.11ac) / Bluetooth 5.2 |
| Audio Decoding |
DTS Neural:X, DTS-ES, DTS-HD High-Resolution, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD |
| HDMI Compliance |
ARC, CEC, eARC |
| Wall Mountable |
Yes, with Included Hardware |
| Soundbar |
|
| Channel Configuration |
13-Channel |
| Enclosure Type |
Sealed |
| Passive Radiators |
2 |
| Low-Frequency Drivers |
4x 1.8 x 3.5" / 45 x 90 mm Front-Firing Cone |
| Midrange Drivers |
2x 1.8 x 2.1" / 46 x 54 mm Up-Firing Cone |
| High-Frequency Drivers |
4x 0.4" / 10 mm Front-Firing Dome
1x 0.9" / 22 mm Front-Firing Dome |
| Full-Range Drivers |
2x 1.8 x 2.1" / 46 x 54 mm Side-Firing Cone |
| Amplifier Output |
585 W |
| Connectivity |
|
| Inputs |
1x HDMI 2.1 - ARC/Audio/Video/eARC |
| Outputs |
1x HDMI 2.1 - ARC/eARC/Audio/Video
1x 1/8" / 3.5 mm - Audio |
| USB I/O |
No |
| Ethernet I/O |
No |
| Wireless Audio Protocols |
AirPlay 2, Bluetooth, Spotify Connect, Wi-Fi |
| Wireless |
Wi-Fi 5 (802.11ac) / Bluetooth 5.2 |
| Bluetooth |
5.2 |
| NFC |
No |
| Bluetooth Profiles |
A2DP, AVRCP |
| Bluetooth Codec Support |
AAC
LDAC
SBC |
| Mobile App Compatible |
Yes: Android & iOS
App Name: BRAVIA Connect
Functionality: Adjust Settings, Remote Control, Setup |
| Compatibility |
|
| Audio Decoding |
DTS Neural:X, DTS-ES, DTS-HD High-Resolution, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD |
| HDMI Compliance |
ARC, CEC, eARC |
| HDR Compatibility |
Yes HDR10, Dolby Vision, Hybrid Log Gamma |
| HDCP Compliance |
HDCP 2.3 |
| Supported Languages |
English
French
Spanish |
| Power |
|
| Power Consumption |
62 W (Soundbar)
< 2.3 W (Network Standby, Bluetooth Standby)
< 0.5 W (Standby) |
| Input Power |
120 VAC, 60 Hz |
| Physical |
|
| Wall Mountable |
Yes, with Included Hardware |
| Dimensions |
51.2 x 2.5 x 4.4" / 1300 x 64 x 113 mm |
| Weight |
12.1 lb / 5.5 kg |
