Chauvet DJ SlimPAR Pro Pix RGBAW+UV LED PAR (Black) has been discontinued, here are some related products you might like:

Chauvet DJ SlimPAR Pro Pix RGBAW+UV LED PAR (Black)

Product #104536 | SKU SLIM PAR PRO PIX | Chauvet
This product is no longer available what does this mean?
Not currently for sale
Contact us for more information
This product is no longer available what does this mean?

Features

  • RGBAW+UV LED PAR for Bright Colour Washes
  • Independent RGB Outer Ring
  • D-Fi USB Compatibility
  • 24° Beam Angle / 41° Field Angle
  • 0-100% Dimming with Selectable Curves
  • 3 DMX Channel Modes

Description

Wash and effect lighting reaches new heights of dynamic power and high-end, rugged features with the Chauvet DJ SlimPAR Pro Pix RGBAW+UV LED PAR. This powerful par is a hex-color (RGBAW +UV) wash light protected by a road-ready die-cast aluminium housing ready to take on the world. SlimPAR Pro Pix has an RGB outer ring which can be independently controlled to thrill viewers.

Create amazing animations and video effects with pixel control of the RGB LEDs. SlimPAR Pro Pix boasts flicker-free video operation making it a great wash light for on-camera use and it’s ideal for quiet installations because it has no moving parts giving it silent operation. powerCON®-compatible power input/output connections for power linking are on board and SlimPAR Pro Pix has D-Fi USB compatibility for wireless master/slave or DMX control and you can easily control static colours and automated programs with the optional IRC-6 remote.

Key Features
  • Hex-colour wash light in die-cast aluminium housing ready to take on the world
  • Create amazing animations and video effects with pixel control (RGB only)
  • Independent control of a separate RGB outer ring to dazzle viewers
  • Flicker-free video operation suitable for on-camera use
  • Ideal for quiet installations due to silent operation and no moving parts
  • powerCON®-compatible power input/output connections for power linking
  • D-Fi USB compatibility for wireless master/slave or DMX control
  • Easily control static colours and automated programs with the optional IRC-6 remote
  • Save time running cables and extension cords by power linking multiple units

Specifications

Light
Fixture Type PAR
Light Source 12 x Colour/UV LED - 10 W / 2.1 A
57 x Colour LED - 11 W / 2.2 A
Light Source Life Expectancy 50,000 Hours
Colours Red, Green, Blue, Amber, White, Ultraviolet
Pixel Configuration 3 x Zones
Photometrics 301.6 fc / 3246 Lux at 6.6' / 2 m
48.2 fc / 519 Lux at 16.4' / 5 m
Lumen Output 2775 Lumens
Beam Angle 25°
Field Angle 39°
Shutter / Strobe Electronic
Iris No
Zoom Adjustment None
Dimming Electronic, 0 to 100%
Performance
Operating Modes Automatic, DMX, Primary/Secondary, Sound-Active, Standalone
Macros / Programmes Colour Macro
Colour Mixing
Sound-Active
Internal Programme
Effects Strobe
Strobe Rate 0 to 20 Hz
Gobos None
Control
Control Protocols DMX512
DMX Channel Modes 3 Mode(s):
12 / 26 / 48-Channel
Display / Controls LED / 4-Button
Remote Control D-Fi USB (with Optional Equipment)
IR Remote (with Optional Equipment)
Connectivity
Inputs/Outputs 2 x XLR 3-Pin DMX Input/Output
2 x XLR 5-Pin DMX Input/Output
Power
AC Input Power 100 to 240 VAC, 50/60 Hz
AC Power Connector Input: 1 x powerCON
Output: 1 x powerCON
Fuse T 2 A 250 V
Power / Current Consumption 120 VAC, 60 Hz: 99 W / 1.4 A
230 VAC, 50 Hz: 96 W / 0.8 A
Power Linking 6 Units at 110 VAC
10 Units at 230 VAC
Total Current: 8 A
Environmental
IP Rating None
Environmental Protection None
Physical
Mounting Dual/Scissor Yoke
Duty Cycle None
Exterior Colour Black
Max Housing Temperature 104°F / 40°C
Cooling Convection
Certifications COE, MET
*as per Manufacturer
Dimensions 11.4 x 12.3 x 4.3" / 29 x 31.2 x 10.9 cm
Weight 9.8 lb / 4.4 kg

In The Box

  • CHAUVET DJ SlimPAR Pro Pix RGBAW+UV LED PAR (Black)
  • Power Cord
