Litepanels Inca 6C LED Fresnel Light
Product #71650 | SKU LP-906-2005
Usually ships in 3 - 4 weeks
0.0 (no ratings yet) Thanks for your rating!


Litepanels Inca 6C LED Fresnel Light

Product #71650 | SKU LP-906-2005
Usually ships in 3 - 4 weeks


Product Features
  • 6" Fresnel.
  • Tungsten-Balanced LED Fixture.
  • 15 to 67° Spot to Flood Beam Angles.
  • Includes Yoke, Barndoors, Power Supply.
  • Dimming from 100 to 0%.
Customer Reviews
0.0 (no ratings yet) Thanks for your rating!
Email me when stock arrives
Product Details
  • Product: #71650
  • SKU: LP-906-2005
Our Price $3,799.00

Delivery - $16.00*
3 - 4 weeks
Pickup AUCKLAND
3 - 4 weeks
Pickup WELLINGTON
3 - 4 weeks
*estimated shipping to Auckland

Overview

The tungsten-balanced Litepanels Inca 6C LED Fresnel Light is a versatile fixture with a 6" Fresnel lens and wide spot-to-flood 15 to 67° beam coverage that can be further controlled with the included 8-leaf barndoors. While drawing only 104W, the Inca 6C produces the heat-free tungsten equivalent of a 650W traditional Fresnel that is dimmable from 100 to 0% without flicker or colour shifting, on the unit or remotely via DMX. Power efficiency means low running and air conditioning costs in the studio and a quick return on investment, while the LED lifespan of thousands of hours makes the Inca 6C virtually maintenance free.

Powering the 6C is equally convenient and flexible. The light's 120-240 VAC power supply make it ready for worldwide use but you can also run on batteries via the light's 3-pin XLR DC power connector when mains current is unavailable.

The Inca 6C light ships with a yoke, 1-1/8" junior pin / 5/8" receiver combo, power supply, power cord, and an 8-leaf barndoor set.

Key Features

  • A true Fresnel fixture with spot or flood directional illumination
  • Litepanels proprietary heat-free LED technology
  • High quality 6" Fresnel lens
  • 104W power draw with illumination comparable to a 650W incandescent Fresnel
  • No noticeable heat generation-reduces air conditioning costs
  • Energy savings and extended lamp life provide a <3 year ROI in typical studio applications
  • Tungsten output colour-matched to incandescent fixtures
  • Versatility in and out of the studio - AC/DC power with DC power via 3-pin XLR
  • Integrated DMX module for remote control using DMX 512 protocol
  • 100 to 0% dimming with no noticeable colour shift (via on-fixture dial or DMX)
  • Focus control from 15 to 67° beam via on-fixture dial or DMX
  • Robust lightweight housing weighs 1/3 as much as conventional Fresnels
  • Standard yoke for easy mounting and positioning
Applications
  • Broadcast Studios
  • Location Lighting
  • Event Lighting
  • Still Lighting
  • Chroma Key
Photometrics

15° Spot @ 10' (3.0 m)

290 fc / 3,290 lux) with 2.9' (0.9 m) beam diameter and 4.8' (1.5 m) field diameter

Flood @ 10' (3.0 m)

35 fc / 370 lux with 14.2' (4.3 m) beam diameter and 18.7' (5.7 m) field diameter

Specifications

Light Fixture
Beam Angle 15 to 67°
Colour Temperature 3200K
Cooling System None
Dimming Yes, 0 to 100%
Display None
Fixture Dimensions 15.0 x 11.0 x 10.0" / 38.0 x 28.0 x 35.0 cm
Fixture Weight 9.1 lb / 4.13 kg
Connectors
Power Input Connector 3-Pin XLR
DMX Connector RJ45
Lens
Lens Diameter 6" / 15.2 cm
Mounting
Fixture Mount Combination 1-1/8" Stud and 5/8" Receiver
Accessory Mount None
Remote Operation
Remote Control Type DMX
Power
AC Input Power 120 to 240 VAC, 50 / 60 Hz
DC Input Power 14 to 28 VDC
Power Source AC Adapter, External Battery
Max Power Consumption 104 W
Physical
IP Rating IP20

In The Box

  • Litepanels Inca 6C LED Fresnel Light.
  • Yoke.
  • Eight-Leaf Barndoor Set.
  • Power Supply.
  • Litepanels AC Power Supply Cord for LP1x1 Fixtures (120VAC).

Reviews

0.0 (no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:
Write a review
Details
  • Product: Litepanels Inca 6C LED Fresnel Light
  • Manufacturer: Litepanels
  • Model: LP-906-2005
  • SKU: LP-906-2005
  • RM Product #: 71650
