Manfrotto FF3512N86 Pantograph with Wire Cable

Overview

The Manfrotto FF3512N86 Pantograph with Wire Cable is made of aluminum and manufactured according to DIN 15560-46. The attachments at both ends of the pantograph are 5/8", male on the top and female on the bottom. The load is supported by a steel cable of 0.08 inch. diameter. It extends from a closed length of 27cm to a maximum extension of 200cm.

Loads of up to 12kg can be suspended using only the friction device, while loads up to a maximum of 18kg require the use of the optional springs. The pantograph can be adjusted to keep suspended loads from 1 to 18kg perfectly balanced.

The colored notched ring can adjust the pantograph's friction; this will ensure that the load remains stable when set in position, but that it will move smoothly up and down when necessary. It is advisable to use springs to aid raising the pantograph. When choosing the additional spring (s) for your pantograph, you will first need to know exactly which model of pantograph you have, in order that you can select the spring of the correct length.

Specifications

• Attachment: 16mm
• Attachment number: 16mm socket
• Maximum extension 200cm
• Folds down to 27cm
• Weighs 4.7kg
• Load capacity 18.0kg
