Features

  • Play 3 Synthesiser Engines at Once
  • 8-Voice Polyphony
  • 8 Built-In Synthesiser Engines
  • Customisable Effects
  • 3 Independent Poly Sequencers and Arps
  • Chance and Action Combo, Randomiser

Description

Simultaneously play three different engines with the Polyend Synth Multi-Engine Polyphonic Desktop Synthesizer Module. It is way more than multi-timbral. Play built-in sequencers or enter notes live. All engine parameters, effects, macros, and grid settings can be saved as an instantly recallable Scene.

Three brand new effect engines

These customizable effects (delay, reverb, modulator) can be independently routed for each synth or effect engine. Use presets or adjust the parameters to your taste.

  • MOD: More than basic modulation. It can go from a slow, smooth chorus through a phaser to wild feedback flanging or anything in between.
  • DEL: A double delay engine has five delay models with delay lines that can be tempo-synchronized or controlled separately.
  • REV: Many reverb sounds can be created using three different reverb modes. Natural to add a touch of realistic space, Plate for metallic reverberations and Warp to add epic ambience from twisted rooms to spiral staircases.
Sequencers and Arpeggiators

Independently assign a sequencer or arpeggiator to each synth and control swing, groove, octave range, gate length, and more. Transposable sequences automatically adapt to the chosen scale.

Smart Grid

Synth is the first device to introduce Smart Grid, an advanced technology that allows for single-button chords and note followers and always be in tune. Stay focused and enjoy even the most hectic live performance.

Polyphonic Aftertouch

A function that responds to your finger’s pressure independently on each pad. Every synth has up to five values that can be controlled with pressure.

Combo Knobs

Combo knobs are customizable macros that can control one, two, or all three synths simultaneously. Instantly add interest to your performance with an epic filter sweep or create an exciting buildup with the twist of a knob.

Specifications

General
Item Type Desktop Synth Module
Sound Generation Digital / Sample-Based
Keyboard No
Touch Sensitivity Yes
Aftertouch Polyphonic Aftertouch (Destination Assignable)
Expression Controls 1x Pitch Bend
Number of Pads 60x Pad
Display Main Display: LCD
AD/DA Conversion 16-Bit / 44.1 kHz
Sounds
Number of Song Presets No
Maximum Polyphony 8 Voice
Multitimbrality 3-Part (Monotimbral)
Built-In Effects Reverb
Delay
Modulation
Performance Functions Arpeggiator, Layer, Sequencer
Built-In Speaker No
Sequencing & Recording
Sequencer Number of Steps: 64x Step
Number of Step Buttons: 60
Number of Parts: 3
Motion Sequencing Yes
Arpeggiator Yes
Connectivity
Audio I/O 1x 1/8" / 3.5 mm TRS Stereo Output
Pedal Support No
MIDI I/O 1x 1/8" / 3.5 mm TRS Type-B Input
1x 1/8" / 3.5 mm TRS Type-B Output
CV/Gate I/O No
Patch Points No
Sync I/O No
Network I/O No
USB I/O 1x USB-C (Bus Power)
Media/Memory Card Slot Single Slot: microSD/microSDHC/microSDXC
Bluetooth No
Compatibility
Included Software No
Required Hardware USB-C Port
Power
Power Requirements USB Bus Power
Eurorack Current Consumption Not Specified by Manufacturer
AC Input Power 100 to 240 VAC, 50 / 60 Hz
AC/DC Power Adapter 5 VDC at 1 A (Included)
Physical
Colour Black
Included Accessories USB Cable
Dimensions 11 x 8.2 x 1.3" / 27.9 x 20.8 x 3.3 cm
Weight 2.6 lb / 1.2 kg

In The Box

  • Polyend Synth Multi-Engine Polyphonic Desktop Synthesiser Module
  • USB-A Power Adapter
  • USB-C Cable
  • 3.5mm TRS to Dual 1/4" Audio Cable
  • 3.5mm to MIDI DIN Adapter (Type B)
  • 16GB MicroSD Card
  • MicroSD to USB-A Adapter
