RCF M1001 Two-Way Speaker System 300W

Product #43208 | SKU 13041015 | RCF
Contact us for an ETA what does this mean?
Our Price $1,019.00
Contact us for an ETA what does this mean?
- +

Email me when stock arrives


Overview

1x10" woofer, vented 1x1" driver, on 90°x60° CD horn

Description

The M1001 is a multipurpose two-way full-range speaker system, suitable in a wide range of installations. The compactness, together with the elegant and neutral design with accurate finishing make M1001 suitable for almost any environment and architectural constraint. Available mounting accessories allow you to use the M1001 wall or ceiling mounted, with reference to the several possible applications.

The M1001 has a controlled dispersion and delivers undistorted SPL value above any expectation from such a compact speaker system.

The M1001 features high sensitivity thanks to the use of oversized magnets and a comfortable sound quality with smooth and wide frequency response performed thanks to the Kapton diaphragm compression driver loaded on a constant directivity horn. The LICC crossover design includes an electronic protection on high frequency device.

Features

  • High Quality 2-way passive loudspeaker
  • 1 x 10" woofer, vented
  • 1 x 1" driver, on 90°x60° CD horn
  • High Power Handling ‘Low Impedance Compensated Crossover', with electronic protection for the driver
  • 300W AES power handling
  • Steel Front Grille with robust double mesh polyester clothing
  • Rotatable RCF front logo
  • Installation points are available on the rear panel, top and bottom
  • All models have a 4-pin EUROBLOCK connector (audio input and parallel link output)
Acoustical Specifications
Frequency Response -10 dB 60 Hz ÷ 20000 Hz
Max SPL @ 1m 128 dB
Horizontal coverage angle 90°
Vertical coverage angle 60°
Directivity index; Q 10
System Sensitivity 97 dB
Nominal Impedance 8 O
Power Handling 300 W
Peak Power Handling 1200 W
Recommended Amplifier 600 W
Protections Dynamic
Crossover frequencies 1700 Hz
Transducers
Compression Driver 1" HF driver, 1.4" voice coil
Nominal Impedance 8 O
Input Power Rating 25 W AES
Sensitivity 106 dB
Woofer 10" Woofer, 2.5" voice coil
Nominal Impedance 8 O
Input Power Rating 250 W AES
Sensitivity 97 dB
Input Section
Input connector 4-pin EUROBLOCK
Cabinet
Cabinet Material MDF 12 mm
Hardware 8 x M6, 2 x M10
Grille Steel, with a robust double mesh polyester clothing
Colour Black
Physical Specifications
Height 500 / 19.68 mm/inch
Width 265/ 10.43 mm/inch
Depth 320 / 12.60 mm/inch
Net Weight 13.2 / 29.08 kg/lbs

Reviews

0.0 (no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:
Write a review

Details

  • Product: RCF M1001 Two-Way Speaker System 300W
  • Manufacturer: RCF
  • Model: M1001
  • SKU: 13041015
  • RM Product #: 43208
